Boat engine bracket AHJE-4V-B-DP
adjustablehydraulic jack platealuminum

Boat engine bracket - AHJE-4V-B-DP - Cook Manufacturing Corporation - adjustable / hydraulic jack plate / aluminum

Add to favorites

Compare this product

Characteristics

Application domain: for boat
Type: adjustable, hydraulic jack plate
Material: aluminum
Max. engine power: 300 ch
(300 hp)
Max. engine weight: 284 kg
(626 lb)
Total height: 318 mm
(13 in)
Total width: 416 mm
(16 in)

Description

Product Overview
The ATLAS™ EDGE Classic hydraulic setback jack plate provides fast, precise outboard height adjustment by pairing a brushless motor with the Smart Gauge control system. It delivers smooth, responsive control for a range of boat speeds, loads and operating conditions. Supports outboards up to 300 HP and 625 lbs dry weight. Manufactured in the U.S.A.

Key Highlights

Brushless motor for fast, low-maintenance operation
Smart Gauge with speed and height controls plus Quick Set positions
Rated for outboards up to 300 HP and 625 lbs dry weight

Features

Brushless motor provides smooth, responsive height adjustment
Smart Gauge: intuitive controls, speed modes, three Quick Set positions and light-sensing display
Three selectable lift speeds: Slow, Medium, Fast
Three Quick Set positions for saved engine heights
Light-sensing display for automatic day/night visibility
Lift Control for manual adjustment and rapid movement
Heavy-duty aluminum construction with black anodized finish
Available setbacks: 4", 6", 8", 10", 12"
Manufactured in the U.S.A.

Specifications

Product Type: Hydraulic setback jack plate
Series: ATLAS™ EDGE
Configuration: Classic / Standard
Finish: Black anodized
Maximum Horsepower: 300 HP
Maximum Engine Weight: 625 lbs (dry)
Width: 16 3/8"
Height: 12 1/2"
Material: Aluminum
Motor Type: Brushless
Controls: Smart Gauge (speed and height controls, Quick Set positions, light-sensing display)
Lift Speeds: Slow, Medium, Fast
Saved Height Positions: Three
Country of Origin: Made in U.S.A.
