Engine control lever HC-3408J

digitalremotedouble

Overview

The HC-3400J is a stand-alone vertical remote control manipulator designed for ergonomic single-joystick operation in demanding marine and industrial environments. It features reinforced sealed construction and a CAN-based control architecture suitable for integration into vessel engine stations and control panels.

Key features

• Single joystick with single-gear and speed control, ergonomic layout for operator comfort
• Dual CAN bus architecture for increased reliability and flexible control modes
• Wide voltage input (9–36 VDC) and redundant CAN power options
• Metal-reinforced, sealed housing tested for waterproofing, salt spray and high-temperature resistance
• Panel-embedded (flush) mounting for clean installation on helm consoles
• Adjustable damping coefficient to tune control feel
• High-precision non-contact linear throttle stroke sensing and one-key dimming for display/illumination

Technical specifications

• Model: HC-3400J
• Control type: single joystick, gear & speed control
• Communication: Dual CAN design, supports individual or synchronized control
• Power supply: 9–36 VDC
• Construction: metal reinforced, sealed enclosure; environmental testing for water, salt spray and heat
• Mounting: panel-embedded
• Sensors: non-contact linear throttle stroke sensor

Installation & compatibility

Designed for integration into helm panels and control consoles, the HC-3400J connects to vessel CAN networks and can be configured for single-station control. Use the dual-CAN architecture to implement redundancy or synchronization with other control units. Recommended for engine control stations, workboats and industrial marine applications.

Related submodels

• HC-3408J — dual-joystick / dual-engine version for synchronized or individual twin-engine control
