Hydraulic windlass XR8

electricfor boatvertical

Vertical windlasses designed for large boats, featuring a robust construction with stainless steel Aisi 316 base, drum, and gypsy cover. Integrated sensor and magnet for precise chain counting. The gypsy band brake with a mobile fixing block allows for multiple hand wheel positions. The gearbox is made of triple-layer painted cast iron, ensuring durability. - Suitable for boats from 32 to 50 meters (105 - 165 ft) - Available models: 5500 W AC, 7500 W AC, HYDRO - Gypsy and Drum diameter: 300 mm (11"13/16) - Gypsy sizes: 19 mm, 20.5 mm, 22 mm - Chain sizes: 17.5 mm, 19 mm, 20.5 mm, 22 mm (STUDLINK) Technical Specifications / Features: - Vertical windlass for large boats - Stainless steel Aisi 316 construction for base, drum, and gypsy cover - Integrated chain counter sensor and magnet - Gypsy band brake with mobile fixing block for multiple hand wheel positions - Triple-layer painted cast iron gearbox - Suitable for boats 32-50 meters (105-165 ft) - Gypsy and drum diameter: 300 mm - Compatible with chain sizes: 17.5 mm, 19 mm, 20.5 mm, 22 mm (studlink) - Available in 5500 W AC, 7500 W AC, and HYDRO models
