Electric windlass Duke - DK6 XY

hydraulicfor boatvertical

Vertical windlasses designed for efficient anchoring. - Constructed with AISI 316 stainless steel and anodized aluminium base - Features a stainless steel drum and gypsy cover - Available with or without drum - Integrated sensor and magnet for chain counter - Safety mechanical band brake - Anodized aluminium gearbox Suitable for boats from 18 to 32 meters (60 - 105 ft). Models: - Duke 3000 W DC for 18 - 27 m (60 - 89 ft) - Duke 3500 W DC for 22 - 29 m (75 - 95 ft) - Duke 4000 W AC for 18 - 29 m (60 - 95 ft) - Duke 5500 W AC for 22 - 32 m (75 - 105 ft) - Duke Hydro for 20 - 32 m (60 - 105 ft) Gypsy and Drum diameter: Ø 200 mm / 7" 7/8 Chain sizes: 12-13 mm, 14 mm - 1/2", 16 mm, 12.5 mm Chain types: ISO, DIN 766, G4, STUDLINK The values refer to a three-strand polyester rope with a rope/chain splice manufactured with the "Slim Splice Quick®" system.
