Steel primer LBE 100

epoxysingle-componentpolyamide

Product overview
Single‑pack epoxy‑amine primer formulated for oven curing at 140–180°C. Designed for the 3‑layer polyethylene (3LPE) external coating cycle of steel pipelines (8–56 in). Applicable by o‑ring (calza) or side‑band methods. Provides resistance to cathodic disbonding and reliable adhesion for subsequent coating layers. LBE 100 is self‑curing, does not require refrigerated storage and can be stored at room temperature.

Usage
SURFACE PREPARATION AND APPLICATION:
Apply on grit‑blasted steel pipes prepared to SA 2.5 in accordance with BS 7079 part A1 or equivalent. Supplied ready for heated application. Where pre‑heating is not possible, can be thinned up to 5% with M.E.K. for spray application.

Technical characteristics

• Paint type: One component
• Binder type: Polyamide‑epoxy
• Color codes: 3P6074 (Black), 3P6938 (Red oxide)
• Specific gravity (kg/L ±0.05): 1.60
• Solids content (weight) ±2: 99%
• Solids content (volume) ±2: 98%
• Shelf life unopened at +23°C (±2): 12 months
• Viscosity (Ford Ø4 at 20°C): 40,000 ±5,000 CPS
• Bucholz hardness: 125

Application data

• Spatula: Ready to use
• Spray: 5–10% thinner 242 (if required)
• Application temperature: +10°C to +40°C
• Relative humidity: Less than 80%
• Dry film thickness advised: 25–100 µm
• Theoretical coverage: 35–40 m²/L for 25 µm; 9–10 m²/L for 100 µm
• In‑line drying / pre‑heating: 140–180°C (depending on application)

Colors

• Black — Color code: 3P6074
• Red oxide — Color code: 3P6938

Safety precautions
Read label and product safety data sheet before use. Observe risk symbols and handling instructions. Dilution rates and drying times are indicative and referenced to 20°C; they may vary with ambient temperature, weather conditions or application process. Store unopened cans at recommended temperature.

Technical specifications

• Product name: Primer LBE 100
• Product codes: 3P6074 / 3P6938
• Type: One component, oven‑curing
• Binder: Polyamide‑epoxy
• Specific gravity: 1.60 kg/L (±0.05)
• Solids by weight: 99% (±2)
• Solids by volume: 98% (±2)
• Viscosity: 40,000 ±5,000 CPS (Ford Ø4 at 20°C)
• Bucholz hardness: 125
• Shelf life: 12 months unopened at +23°C (±2)
• Application temp: +10°C to +40°C
• Recommended DFT: 25–100 µm
• In‑line drying: pre‑heating 140–180°C
