Ship navigation light JN-NAV-016D-P-S

LEDredbase-mounted

Short description
Single-lens LED starboard navigation light JN-NAV-016D-P-S for vessels ≥50 m in length — 8 W, green signal, 3 NM visibility, IP56, CCS approved.

Features

• CCS approved for vessels ≥50 m
• Ingress protection: IP56
• Power consumption: 8 W
• Input voltage: 100–240 VAC
• Output voltage: 12–24 VDC
• LED driver: Constant current
• LED type: SMD
• Nominal visibility range: 3 NM
• Horizontal sector (level arc): 112.5°
• Signal color: Red
• Housing colour: Black
• Housing material: PA+GF body, PC lampshade, stainless steel lens hood
• Mounting: 4-hole flange (Φ10–Φ12 cable entry)
• Operating temperature: -25°C to +55°C
• Warranty: 3 years
• IMPA code: 371121

Product Specifications
SKU: JN-NAV-016D-P-S
Power consumption: 8 W
Input voltage: 100–240 VAC
Output voltage: 12–24 VDC
IP rating: IP56
Certifications: CCS approval (suitable for vessels ≥50 m)
Housing colour: Black
Housing material: PA+GF housing, PC lampshade, stainless steel lens hood
Mounting: 4-hole flange (Φ10–Φ12 cable entry)
Visibility range: 3 NM
Level arc: 112.5°
Signal color: Green
LED driver: Constant current
Working temperature range: -25°C to +55°C
Warranty period: 3 years
IMPA code: 371121

Packaging & Shipping
Product dimensions (mm): 215 x 215 x 215
Net weight: 1.5 kg
Export carton dimensions (mm): 500 x 250 x 250
Products per carton: 1
Export carton gross weight: 5 kg
Fixture height (mm): 215
Fixture width (mm): 215
Fixture length (mm): 500

Additional information

• Power (W): 8
• Voltage: 100–240 VAC
• IP rating: IP56
• LED type: SMD
• Certifications: CCS approval
• Housing colour: Black
• Housing material: PA+GF housing, PC lampshade, stainless steel lens hood
• Mounting: 4-hole flange (Φ10–Φ12 cable entry)
• Warranty: 3 years

Technical specifications

• SKU: JN-NAV-016D-P-S
• Power consumption: 8 W
• Input voltage: 100–240 VAC
• Output voltage: 12–24 VDC
• LED driver: Constant current
• LED type: SMD
• IP rating: IP56
• Certifications: CCS approval (vessels ≥50 m)
• Housing: PA+GF body, PC lampshade, stainless steel lens hood
• Mounting: 4-hole flange (Φ10–Φ12 cable entry)
• Visibility: 3 NM
• Level arc: 112.5°
• Signal color: Green
• Operating temperature: -25°C to +55°C
• Warranty: 3 years
• IMPA code: 371121
• Product dimensions (mm): 215 x 215 x 215
• Net weight: 1.5 kg
