Ship navigation light JN-NAV-016D-AR-S

LEDwhitebase-mounted

Short description
Single-lens LED starboard navigation light JN-NAV-016D-AR-S designed for vessels ≥50 m; 8 W power, IP56 protection and CCS approval.

Features

• CCS approval for vessels ≥50 m
• IP56 protection rating
• Visibility range: 3 NM
• Level arc: 112.5°
• Signal colour: Green
• LED type: SMD with constant-current driver

Product Specifications

• SKU: JN-NAV-016D-AR-S
• Power consumption: 8 W
• Input voltage: 100–240 VAC
• Output voltage: 12–24 V DC
• IP rating: IP56
• Certifications: CCS approval
• Housing colour: Black
• Housing material: PA+GF body, PC lampshade, stainless steel lens hood
• Mounting: 4-hole mounting (Φ10–Φ12 cable entry)
• Operating temperature: -25°C to +55°C
• Warranty: 3 years

Packaging & Shipping

• Product dimensions (mm): 215 x 215 x 215
• Net weight: 1.5 kg
• Export carton dimensions (mm): 500 x 250 x 250
• Products per carton: 1
• Export carton gross weight: 5 kg
• Fixture height x width x length (mm): 215 x 215 x 500

Additional information

• Power (W): 8
• Voltage: 100–240 VAC
• IP rating: 56
• LED type: SMD
• Certifications: CCS approval
• Base / socket: 4-hole mounting (Φ10–Φ12 cable entry)
• Warranty (years): 3

Characteristics / Technical specifications

• SKU: JN-NAV-016D-AR-S
• Power consumption: 8 W
• Input voltage: 100–240 VAC
• Output voltage: 12–24 V DC
• LED type: SMD
• LED driver: Constant current
• IP rating: IP56
• Certifications: CCS approval for vessels ≥50 m
• Housing: PA+GF body; PC lampshade; stainless steel lens hood
• Mounting: 4-hole mounting (Φ10–Φ12 cable entry)
• Warranty: 3 years
• Visibility range: 3 NM
• Level arc: 112.5°
• Signal colour: White
• Operating temperature: -25°C to +55°C
• Product dimensions (mm): 215 x 215 x 215
• Net weight: 1.5 kg
