Ship navigation light JN-NAV-008S-P-S

LEDredbase-mounted

Short description
Single Lens LED Starboard Light designed for vessels ≥50 m in length. Green signal, 3 NM visibility, 112.5° vertical arc.

Product Specifications
Product SKU: JN-NAV-008S-P-S
Power Consumption: 8 W
Input Voltage: 100~240VAC
IP Rating: IP56
Certifications: CCS approval (approved for vessels ≥50 m)
Housing Colour: Black
Housing Material: PA+GF housing, PC lampshade, Stainless steel lens hood
Socket/Base Type: 4 hole mounting (Φ10~Φ12 cable entry)
Warranty Period (Years): 3
IMPA Code: 371121
Visibility Range (NM): 3 NM
Level Arc: 112.5°
Signal Color: Green
Output Voltage: 12-24VDC
LED Driver: Constant Current
Particulars: CCS approved for vessels ≥50 m, IP56 rated
Working Temperature Range: -25°C to +55°C

Packaging & Shipping
Product Dimensions (mm): 215x215x215
Net Weight (kg): 1.5 kg
Export Carton Dimensions (mm): 300x250x250
Products per Carton: 1
Export Carton Gross Weight (kg): 3 kg
Fixture Height (mm): 215
Fixture Width (mm): 215
Fixture Length (mm): 285

Additional information
Power (W): 8
Voltage: 100~240VAC
IP Rating: IP56
LED Type: SMD
Certifications: CCS approval
Housing Colour: Black
Housing Material: PA+GF housing, PC lampshade, Stainless steel lens hood
Base / Socket: 4 hole mounting (Φ10~Φ12 cable entry)
Warranty (yr): 3

Technical specifications / features

• SKU: JN-NAV-008S-P-S
• Power consumption: 8 W
• Input voltage: 100~240VAC
• Output voltage: 12-24VDC
• IP rating: IP56
• Certifications: CCS approval (approved for vessels ≥50 m)
• LED type: SMD with constant current driver
• Signal color: Green
• Visibility range: 3 NM
• Vertical/level arc: 112.5°
• Housing: PA+GF housing, PC lampshade, stainless steel lens hood (black)
• Mounting / base: 4 hole mounting (Φ10~Φ12 cable entry)
• Working temperature range: -25°C to +55°C
• Warranty: 3 years
• Dimensions (product): 215 x 215 x 215 mm; Fixture length: 285 mm
• Net weight: 1.5 kg
