Ship navigation light JN-NAV-008S-AR-S

LEDwhitesurface-mount

Short description
Single-lens LED starboard navigation light designed for vessels of 50 metres and above. Compact 8 W unit with IP56 protection and CCS approval, suitable for fixed installation on commercial and recreational vessels.

Product Specifications
Product SKU: JN-NAV-008S-AR-S
Power Consumption: 8 W
Input Voltage: 100~240VAC
IP Rating: IP56
Certifications: CCS approval (for vessels ≥50 m)
Housing Colour: Black
Housing Material: PA+GF housing, PC lampshade, stainless steel lens hood
Socket/Base Type: 4-hole mounting (Φ10~Φ12 cable entry)
Warranty Period (Years): 3
IMPA Code: 371121
Visibility Range (NM): 3 NM
Level Arc: 112.5°
Signal Color: White
Output Voltage: 12-24VDC
LED Driver: Constant current
Particulars: CCS approved for vessels ≥50 m, IP56 rated
Working Temperature Range: -25°C to +55°C

Packaging & Shipping
Product Dimensions (mm): 215 x 215 x 215
Net Weight (kg): 1.5 kg
Export Carton Dimensions (mm): 300 x 250 x 250
Products per Carton: 1
Export Carton Gross Weight (kg): 3 kg
Fixture Height (mm): 215
Fixture Width (mm): 215
Fixture Length (mm): 285

Technical specifications

• SKU: JN-NAV-008S-AR-S
• Power Consumption: 8 W
• Input Voltage: 100~240VAC
• Output Voltage: 12-24VDC
• IP Rating: IP56
• Certifications: CCS approval (approved for vessels ≥50 m)
• Housing Colour: Black
• Housing Material: PA+GF housing; PC lampshade; Stainless steel lens hood
• Socket/Base: 4-hole mounting (Φ10~Φ12 cable entry)
• Visibility Range: 3 NM
• Level Arc: 112.5°
• Signal Color: Green
• LED Type: SMD
• LED Driver: Constant current
• IMPA Code: 371121
• Warranty: 3 years
• Operating Temperature: -25°C to +55°C
• Product Dimensions (mm): 215 x 215 x 215
• Net Weight: 1.5 kg
