Ship navigation light JN-NAV-016D-MH-S

LEDwhitenavigation light

Short description
Single-lens LED starboard navigation light designed for vessels ≥50 m in length with CCS approval and IP56 protection.

Product Specifications

• Product SKU: JN-NAV-016D-MH-S
• Power Consumption: 8 W
• Input Voltage: 100–240 VAC
• IP Rating: IP56
• Certifications: CCS approval
• Housing Colour: Black
• Housing Material: PA+GF housing, PC lampshade, stainless steel lens hood
• Socket / Base Type: 4-hole mounting (Φ10–Φ12 cable entry)
• Warranty Period: 3 years
• IMPA Code: 371121
• Visibility Range: 3 NM
• Degree of Visibility / Arc: 112.5°
• Signal Color: Green
• Output Voltage: 12–24 VDC
• LED Driver: Constant current
• Certification Notes: CCS approved for vessels ≥50 m, IP56 rated
• Working Temperature Range: -25°C to +55°C

Packaging & Shipping

• Product Dimensions (mm): 215 x 215 x 215
• Net Weight: 1.5 kg
• Export Carton Dimensions (mm): 500 x 250 x 250
• Products per Carton: 1
• Export Carton Gross Weight: 5 kg
• Fixture Height (mm): 215
• Fixture Width (mm): 215
• Fixture Length (mm): 500

Additional attributes

• Power (W): 8
• Voltage: 100–240 VAC
• IP Rating: IP56
• LED Type: SMD
• Certifications: CCS approval
• Housing Material details: PA+GF housing, PC lampshade, stainless steel lens hood
