Boat navigation light JN-NAV-016D-SB-S

for shipsLEDgreen

Product Overview
Single-lens LED starboard navigation light designed for vessels ≥50 m in length. Compact, IP56-rated navigation fixture with green signal colour and 3 NM visibility.

Key highlights

• 8 Watt power consumption
• CCS approval — approved for vessels ≥50 m in length
• Visibility range: 3 NM
• Level arc: 112.5°
• Signal colour: Green

Product Specifications
Product SKU: JN-NAV-016D-SB-S
Power Consumption: 8 W
Input Voltage: 100~240 VAC
IP Rating: IP56
Certifications: CCS approval
Housing Colour: Black
Housing Material: PA+GF housing; PC lampshade; Stainless steel lens hood
Socket/Base Type: 4 hole mounting (Φ10~Φ12 cable entry)
Warranty Period (Years): 3
IMPA Code: 371121
Visibility Range (NM): 3 NM
Level Arc: 112.5°
Signal Color: Green
Output Voltage: 12-24 VDC
LED Driver: Constant Current
Particulars: CCS approved for vessels ≥50 m, IP56 rated
Working Temperature Range: -25°C to +55°C

Packaging & Shipping
Product Dimensions (mm): 215 x 215 x 215
Net Weight (kg): 1.5 kg
Export Carton Dimensions (mm): 500 x 250 x 250
Products per Carton: 1
Export Carton Gross Weight (kg): 5 kg
Fixture Height (mm): 215
Fixture Width (mm): 215
Fixture Length (mm): 500

Technical characteristics

• SKU: JN-NAV-016D-SB-S
• Power: 8 W
• Input voltage: 100~240 VAC
• Output voltage: 12-24 VDC
• IP rating: IP56
• Certifications: CCS approval
• Housing colour: Black
• Housing material: PA+GF housing; PC lampshade; Stainless steel lens hood
• Socket / Base: 4 hole mounting (Φ10~Φ12 cable entry)
• Warranty: 3 years
• IMPA Code: 371121
• Visibility range: 3 NM
• Level arc: 112.5°
• Signal colour: Green
• LED driver: Constant Current
• Particulars: CCS approved for vessels ≥50 m, IP56 rated
• Operating temperature: -25°C to +55°C
• Product dimensions (mm): 215 x 215 x 215
• Net weight: 1.5 kg
