cheek block / single / with fixed head / max. rope ø 12 mm
RF50100 Ronstan

{{requestButtons}}

Characteristics

  • Type:

    cheek

  • Number of sheaves:

    single

  • Configuration:

    with fixed head

  • Maximum line diameter:

    max. rope ø 12 mm

  • Application domain:

    for sailboats

  • Applications:

    halyard, spinnaker

  • Working load:

    500 kg (1,102.3 lb)

  • Breaking load:

    1,500 kg (3,306.9 lb)

Description

Features

Low friction, 2-stage ball bearing system
High static and dynamic load capacity
Lightweight
Cheek cut-outs for easy bearing maintenance
Captive Lock™ universal head
Slotted pin shackle eliminates fouled lines
