... model offers an outstanding value for money + dimensions Technical data: Length pin to pin closed / open: 250 / 310 mm Toggle length x width: 15 x 20 mm Pin diameter: 12 mm Stud diameter: 12 mm For wire diameter: ...
... The handle model offers great comfort during operations Technical data: Length pin to pin closed / open: 310 / 450 mm Toggle length x width: 10 x 10 mm Pin diameter: 8 mm Stud diameter: 8 mm For wire diameter: ...
... offers great comfort and ease of use during operations. Technical data: Length pin to pin closed / open: 360 / 520 mm Toggle length x width: 17 x 22 mm Pin diameter: 12 mm Stud diameter: 14 mm For wire diameter: ...
GALVANIZED TURNBUCKLES Code 377-05, Dimensions 5 mm Code 377-06, Dimensions 6 mm Code 377-08, Dimensions 8 mm Code 377-10, Dimensions 10 mm Code 377-12, Dimensions 12 mm Code 377-14, Dimensions ...
ΙΝΟΧ TURNBUCKLES CodeDiameterUnit 03222-66 mmUNIT 03222-88 mmUNIT
Specifications Weight: 87.00 g Thread size: 1/4" L-MIN: 135 mm L-MAX: 199 mm Clevis pin Ø: 6.50 mm F-WIDTH: 7 mm H: 12.50 mm Breaking Load: 1550 kg
SPECIFICATIONS Weight: 29.00 g Wire diam: 3 mm Thread size: 1/4" L-MIN: 69 mm L-MAX: 139 mm Clevis pin Ø: 6.50 mm W: 7 mm H: 6.50 mm Breaking Load: 1550 kg
SPECIFICATIONS Weight: 52.00 g Thread size: 1/4" L-MIN: 150 mm L-MAX: 220 mm Clevis pin Ø: 6.50 mm H1: 12.50 mm W: 7 mm H2: 15.00 mm Breaking Load: 1550 kg
Description: Open Body Turnbuckle Eye/Eye Material: SS304/SS316 Size:From M5 to M20 Surface Treatment:"EP" (Electro Polished)
Description: Open Body Turnbuckle Hook/Eye Material: SS304/SS316 Size:From M5 to M20 Surface Treatment:"EP" (Electro Polished)
Practical and functional system coupling and quick release for Babystay with toggle quick pin at the bottom side.
Back-Stay adjuster calibrated - AISI 316/inside thread on bronze "HR" with nr. 2 handless (AISI 316)
... open barrel turnbuckles in large and small sizes, in addition to convenient locking turnbuckles. Tie Downs - Turnbuckles and Padeyes Make A Complete Package You have come to expect ...
Threaded shaft and threaded eye end in polished 316L stainless steel.
Threaded shaft and threaded toggle fork end in polished 316 stainless steel. Supplied with shaft and ring.
... Use of dissimilar but compatible metals avoids the risk of thread seizure Toggle end provides full lateral articulation and connection compatability Threaded eye, toggle and swage terminal end options availab
Rigging screws with two fixed jaws AISI 316 stainless steel
Sturdy turnbuckles made of stainless steel with precisely cut thread.
A6110 Rigging Screws Fork / Fork Rigging Screw 316 Stainless steel rigging screws
Description:Stay Adjuster Finetune Category:Spars and Rigging Subcategory:Rigging Adjusters Type:Stay Adjusters Weight (grm):38 Length (mm):75
... Forged from high strength Bronze alloy. High quality polished chromium finish. Stronger than the wire rope. Toggle action allows full articulation. Wide selection of end fittings available. Thread ...
BTM handle stay tensioners are available in different sizes to be used either on 1x19 wire stays with diameter from 8 mm to 22 mm, or rod equivalent The mechanism is to be operated through a clutch for standard wich handle. BTM stay ...
Fork/Fork Metric High Polished Stainless Steel – AISI 316 The price favourable and durable Stainless Steel Rigging Screw line from Blue Wave has been a favourite among Riggers and yachtsmen for the last 50 years. ...
Originally developed by Navtec using a cold-drawn process, the high-strength, low-stretch, corrosion-resistant Nitronic 50 rod is the industry standard. It is available in coil form in rod sizes up to -76 and in bar form for -76 and above. ...
... lashing lengths 8-14 inches long. Lashing to a turnbuckle using our male distributors often is a good option if the pin to pin length is not accurately known. Turnbuckle Tensioners: Jaw to Jaw turnbuckles ...
Sparcraft Rigging assembles and sells quality standing and running riggings. SP.R is based near RDM Sparcraft in La Rochelle, with whom a synergy allows to offer a mast/rigging package. The selected parts are manufactured with the best ...
Available finishes Electrogalvanized Application areas Marine Urban fabric Hardware Livestock farming Food industry Industry Note Commercialized product
The Hand Swage Stud and Stud Turnbuckle fits cable sizes 1/8" and 3/16". This hand swage turnbuckle features two hand swage studs and an open style body. It is made used in marine, industrial and architectural ...
How to choose this product
A rigging screw is a fitting for tightening or loosening cables with fixed ends. NauticExpo offers a wide variety including forked and hydraulic versions, and models with an articulated pin.
These devices usually are used to tension sailboat standing rigging, essentially shrouds and stays.
This metal fitting has an open or closed cylindrical body whose ends are tapped. Hooks, screw eyes or shackles are fastened to the ends. Some are hydraulic.
How to choose
Choice will depend on the size and specific function of the cable or line to be tensioned. Other criteria include open or closed body, and whether the end will hold a hook, an eye screw or a shackle.
