Mechanical windlass HR5

electrichydraulicmanual

Horizontal on-deck windlasses - Painted aluminum base (RAL 9010) - With and without drum - Rope and chain on a single gypsy - Emergency ratchet-operated manual lift system - Integrated solenoids unit - Manual Free-Fall system - Safety mechanical band brake - IP66 watertight motor For boats from 12 to 24 metres (39 - 79 ft) Heroes 1700 W: 12 - 16 m (39 - 52 ft) Heroes 2300 W: 15 - 20 m (49 - 66 ft) Heroes 3000 W: 20 - 24 m (66 - 79 ft) Heroes AC 3000 W: 15 - 20 m (49 - 66 ft) Available on request with hydraulic motor (HR5 Hydro) Gypsy and Drum: Ø 150 mm / 6"21/64 GYPSY: 10 mm - 3/8", 12/13 mm, 14 mm CHAIN: 10 mm, 12 mm, 13 mm, 14 mm The values in the table refer to a three-strand polyester rope with a rope/chain splice manufactured with the "Quick®" system. This product includes 4 models: 1700/D/DB, 2300/D/DB, 3500/D/DB, 3000 AC /D Technical Specifications: - Product type: Horizontal on-deck windlass - Base material: Painted aluminum (RAL 9010) - Drum: With and without drum options - Gypsy: Rope and chain on a single gypsy - Manual lift: Emergency ratchet-operated - Solenoids: Integrated unit - Free-Fall: Manual system - Brake: Safety mechanical band brake - Motor: IP66 watertight - Boat size compatibility: 12-24 m (39-79 ft) - Power options: 1700 W, 2300 W, 3000 W, AC 3000 W - Gypsy and drum size: Ø 150 mm / 6"21/64 - Chain sizes: 10 mm (ISO P.30), 12 mm (ISO), 13 mm (DIN 766), 14 mm (DIN 766) - Hydraulic motor version available on request (HR5 Hydro)
