Ship generator set 3512C

diesel

GENERATOR SET SPECIFICATIONS Minimum Rating - 1550 eKW (1937 kVA) Maximum Rating - 1700 eKW (2125 kVA) Frequency - 60 hz Speed - 1800 ENGINE SPECIFICATIONS Configuration - Vee 12 4-Stroke-Cycle Diesel Aspiration - TTA Bore - 170 mm Stroke - 215 mm Displacement - 58.56 l GENERATOR SET CONFIGURATIONS Emissions - IMO II GENERATOR SET DIMENSIONS Length - 5085.3 mm Width - 2142.1 mm Height - 2131.1 mm Weight - Estimated - 12762 kg AIR INLET SYSTEM Corrosion resistant separate circuit aftercooler core, regular duty air cleaners, dual turbochargers CONTROL SYSTEM Caterpillar A-III electronic engine control, Electronic Unit Injection fuel system, rigid wiring harness COOLING SYSTEM Auxiliary fresh water pump, centrifugal non-self-priming auxiliary sea water pump, gear driven centrifugal jacket water pump, expansion tank, engine oil cooler, thermostats and housing EXHAUST SYSTEM Dry gas-tight exhaust manifolds with heat shields, dual turbochargers with water-cooled bearings and heat shields, vertical exhaust outlet FLYWHEELS & FLYWHEEL HOUSINGS Flywheel, SAE No. 00, 183 teeth Flywheel housing, SAE No. 00 FUEL SYSTEM Fuel filter, RH, with service indicators Fuel transfer pump Electronically Controlled Unit Injectors INSTRUMENTATION Engine mounted instrument panel with four position switch, over speed shutdown notification light, emergency stop notification light, graphical display unit for analog or digital display of: oil and fuel pressure, oil and fuel filter differential, system DC voltage, exhaust and water temperature, air inlet restriction, service meter, engine speed, fuel consumption (total and instantaneous)
