6.60 m
21' 8"
|
|
|
With its strong construction and being just 6.5 metres from bow to stern, this centre console RIB makes an ideal tender for the smaller launch.
It is easily manoeuvrable in heavy water traffic and just as easy to manage when towing on open roads, even with a smaller vehicle.
This model has also been received favourably by Maritime Police Departments for rapid response intervention and has been embraced by the leisure boat market.
|
|
|
|
6.70 m
22' 0"
|
|
|
|
Based on the fiberglass 22 foot Primatist hull, the boat designed by Bruno Abbate for the naval corp of the "Carabinieri", ensures the best conditions for the tasks of patrol and control. One spacious nav cabin allows a any-weather-use, while the perfect visibility in any direction is granted by large windows and windshield. Equipped with one 130 hp turbodiesel engine, the boat joints extraordinary handle and stability qualities and 35 knots maximum speeds and 30 knots cruise speed.
|
|
|
|
8.10 m
26' 7"
|
|
|
The Vector 23 midcabin is based on Vector ProBoats proven 7meter deep V hull. Designed and dimensioned for speeds + 50 knots. The general arrangement is optimized for fast transport of a 5 man crew. The helm station features excellent ergonomics with large panel surfaces for the fitting navigation and communication equipment. A cuddy cabin in front of the wheelhouse offers overnight capabilities/ dry stowage. Optionally the boat can be built with an open working deck in front. Outboard propulsion 175 – 350 HP.
LOA: 8,10 m
L,hull: 7,05 m
BOA: 2,10 m
B,hull: 2,00 m
Deadrise: 24 degrees
Dry weight: ca. 1 600 kg
Engine: 175 - 350 Hk
Fueltank: ca. 200 L
Speed: +40 knots
|
|
|
|
8.50 m
27' 11"
|
|
|
Boats TM-825 OB and IB series are designed for patrol see area, fishing guard, police, special force, and sport.
TM-825 2OB Open
Specification:
- Length overall - 8,50 m
- Rigid hull length - 7,50 m
- Beam - 3,00 m
- Draft w/o eng. - 0,60 m
- Weigh dry.no eng. - 1350 kg
- Design. displac. - 2,65 m3
- Aver.chamber diam. - 0,57 m
- Person capacity - 8(12)
- Max power - 2x200HP
- Design.speed - 45 kn
- Fuel capacity - 300 dm3
- Transom height - 0,76 m
CE design category B
|
|
|
|
9.00 m
29' 6"
|
|
|
STM 9000 Patrol is a high-speed multi-purpose motor vessel.
The vessel is intended for multi-purpose use (as a pleasure boat, pilotage vessel, patrol vessel, salvage boat, etc.)
The vessel is intended for operation in a coastal zone of seas and large lakes with the distance from ports/havens not less than 60 miles.
The vessel is a catamaran. The hulls of this catamaran have three pair apray rails.
The vessel has elongated cabin with good visibility and space for 8 persons. The control panel is placed there, seats for 6 persons and toilet.
The vessel has an extensive board-to-board cockpit about 3,5 m long for
storing equipment. Spacious lockers in the cockpit can be used for moorings storage, etc., their lids provides seats for passengers.
|
|
|
|
9.39 m
30' 10"
|
|
|
|
The wide variety of features offered by Targa make our boats an ideal choice for professional use. A Targa meets the special demands of different professionals and working needs. Professionals who have already noticed and enjoyed the benefits of Targa boats include: divers, journalists, taxiboat operators, the police, lifeguard service and oil exploration companies. A spacious deck, large hold and excellent performance at sea from very early spring till late autumn also make Targa suitable for pleasure fishermen. Targa boats offer almost limitless possibilities.
|
|
|
|
9.50 m
31' 2"
|
|
|
Boats TM-925 series are the most popular Techno Marine boats designed for patrol see area, chartering and watersport.
TM-925 IB Open
Specification:
- Length overall - 9,50 m
- Rigid hull length - 9,50 m
- Beam - 3,08 m
- Draft w/o eng. - 0,68 m
- Weigh dry.no eng. - 1950 kg
- Design. displac. - 4,15 m3
- Aver.chamber diam. - 0,57 m
- Person capacity - 12(16)
- Max power - 2x270HP
- Design.speed - 40 kn
- Fuel capacity - 500 dm3
CE design category B
TM-925 2OB Open
Specification:
- Length overall - 9,50 m
- Rigid hull length - 9,50 m
- Beam - 3,08 m
- Draft w/o eng. - 0,65 m
- Weigh dry.no eng. - 1850 kg
- Design. displac. - 3,85 m3
- Aver.chamber diam. - 0,57 m
- Person capacity - 12(16)
- Max power - 2x250HP
- Design.speed - 45 kn
- Fuel capacity - 500 dm3
- Transom height - 0,76 m
CE design category B
|
|
|
|
10.00 m
32' 10"
|
|
|
The Vigilante Professional Workboat range is designed specifically to meet the varied challenges presented to workboat operators in the contemporary marketplace. The team, work continuously with customers and suppliers to develop and perfect the finished product.
Vigilante Professional Workboat Range: -
* 10m GRP Pilot Boat
* 10m GRP Survey/Patrol Boat
* 16m Aluminium Survey Catamaran
* 16m Aluminium Crew/Wind Farm Support Catamaran
* 22.5m Aluminium Crew Boat (mono hull)
|
|
|
|
10.06 m
33' 0"
|
|
|
|
Now more than ever, port security is of critical concern for local governments as well as within the private sector alike. The M2 is an ideal harbor patrol boat due to its shallow draft, high degree of maneuverability and ability to intercept potential security threats in and around our nation's ports. Its rugged design and fully outfitted cabin make it well-suited for extensive patrol shifts, marine security details and harbor inspection operations.
|
|
|
|
10.21 m
33' 6"
|
|
|
|
From open-water rescue to recovery dive operations, today's law enforcement vessels are put to test on a daily basis in challenging marine environments for a variety of calls to service. The M2 design affords its users a stable platform for responding to emergency calls, rapid response times and a highly maneuverable vessel with shallow water access.
|
|
|
|
10.67 m
35' 0"
|
|
|
Boomeranger wheelhouse cabin RIBs are mostly used for Patrol, Military and Search & Rescue duties.
These boats have excellent speed and sea keeping capabilities as is typical to RIB boats but they also have ergonomic wheelhouse providing excellent work space for the crew as well as good space for all the necessary electronics and controls. These boats are very well protected against the elements and thus suitable for prolonged use in the harshest environments.
|
|
|
|
10.67 m
35' 0"
|
|
|
Since 1991 Boomeranger Boats Ltd. has built boats made of GRP. Later on the polyethylene hulls became a major business and during 2004 Boomeranger will unveil an all new concept, aluminum RIB. The aluminum production facilities have been established and the first order has already been received. The boat now under construction is launched on August 2004 starting a new branch in shipyard's model line.
Boomeranger aluminum RIBs will push commercial vessel boundaries to a new dimension by using this lightweight metal in a way never seen before in workboat building. The yet unveiled method is clever and allows to build strong and lightweight hulls with equal or even better performance profile compared to GRP models.
All familiar Boomeranger characteristics like high level of customisation and unrivalled quality are standard features also in our aluminum models. By offering RIBs with three different hull materials, Boomeranger Boats has now the widest range of custom RIBs available in the commercial marine industry.
|
|
|
|
11.00 m
36' 1"
|
|
|
The 11.00 metre X2K is an advanced, high speed design which can be configured for sheer pleasure, commercial, patrol or military use. It offers superior sea-keeping, efficiency, speed and safety in all operating conditions and is well suited for offshore fishing and coastal passages. With speeds of 52 + knots with twin 250 hp outboards, 43 knots with 2 x 175 hp, and 35 knots with 2 x 140 hp. This cutting-edge design is based on the latest offshore racing hulls and has a ventilated double step, pad keel and a notched transom. The longitudinal underwater steps reduce hull resistance when planning.
The centre console configuration gives full walk-around convenience and contains a practical and private toilet with shower. For those with a "NEED FOR SPEED" the steering station is fitted with restraining, racing type seats for standing or seated driving positions. The aft deck has a removable 4 person sofa so it can be open for fishing, diving, water sports, light cargo. There is space for additional seating for passengers, or this area can be complimented with a bench unit with sink that provides extra storage and houses a removable 70 lt. icebox. A low profile bench seat with built-in icebox is also available. Forward is the social centre, with a double sofa and two single seats and space for a removable table. The forward cabin has a double Vee berth, suitable for the "Guys", or for friendlier couples.
|
|
|
|
11.00 m
36' 1"
|
|
|
Four man console with foot straps & 30 mm heavy duty A4 stainless steel brackets
2500 litres fuel tank under the deck with pipe for cleaning
Sea through water seperator & fuel filter
A4 stainless steel grab handles on console
|
|
|
|
11.70 m
38' 5"
|
|
|
Boomeranger wheelhouse cabin RIBs are mostly used for Patrol, Military and Search & Rescue duties.
These boats have excellent speed and sea keeping capabilities as is typical to RIB boats but they also have ergonomic wheelhouse providing excellent work space for the crew as well as good space for all the necessary electronics and controls. These boats are very well protected against the elements and thus suitable for prolonged use in the harshest environments.
|
|
|
|
12.00 m
39' 4"
|
|
|
Megatech 12 Cabin: 12 meter boat, GRP hull and Neoprene Hypalon tubes, designed for patrol duties and maritime surveillance.
Fitted with two 440 HP engines and water jet propulsion.
Inside the cabin is equipped with three person autonomous and shock absortion seats, instruments and complete electronics with radar, GPS, VHF, depth sounder, mobile phone etc...air conditioning, toilet and oven are other components inside cabin.
The first units have beed delivered to the Guardia Civil Corp in Spain and further units are being built at this moment.
|
|
|
|
12.50 m
41' 0"
|
|
|
Length overall(m) 11,89
Rigid length overall (m) 11,59
Beam overall (m) 3,58
Designed draft (m) 0,60
Designed displacement (m) 6,40
Chamber diameter (m) 0,55
Chamber quantity (pcs) 12
Light mass of boat (t) 2,90
Total mass of boat (t) 12
Standard engine(s) (HP) 4 x 200
Max power (HP) 4 x 250
Cruising speed (kn) 25
Max speed (kn) 60
Max person (pers) 4
Min crew (pers) 2
Fuel tank(s) capacity (dm3) 3600
Cargo capacity (kg) 6000
|
|
|
|
12.50 m
41' 0"
|
|
|
|
|
|
12.50 m
41' 0"
|
|
|
The XL Cabin is a semi-industrial RIB that caters for the needs of busy waterways. The size of this boat makes it ideal for multiple personnel or small goods transfer.
The extra length and stability of this model offers a wide range of practical uses including police launches, customs and fire services and armed forces units.
|
|
|
|
13.00 m
42' 8"
|
|
|
|
Coastal patrol team, "Miami Vice" style: this is the first impression you have, seeing in port the V.6100 in force in the fleet of the naval corp of the Italian Customs Office. The builder is Bruno Abbate's shipyard, one of the most famous Italian builders, specialized in pleasure boats. Abbate's name, by the way, also ensures the sporty temper of this boat, considering the designer'r past as a winning world pilot.
|
|
|
|
15.20 m
49' 10"
|
|
|
Destination:
Vessel is designed for patrol guard and coastguard in territorial waters of Estonia in conditions of high sea. Vessel is able to operate in broken ice and in conditions appeared at passing ice.
|
|
|
|
18.00 m
59' 1"
|
|
|
The "Glücksburg"
and "Greif" Patrol Boats
These 18-m patrol boats where built based on a well proven design for the German custom authority. By using a standard hull design Fassmer is flexible to adopt clients requirements concerning accommodation, layout of superstructure and deck equipment. In any case the standard deep-vee hull form will guarantee a high seaworthiness, good dynamic stability and manoeuvrablity.
Special Features
marine crane, 4 m rubberdinghy
|
|
|
|
26.52 m
87' 0"
|
|
|
USCG CPB 87'
This unique vessel is a multi-mission platform capable of performing Search and Rescue (SAR), Law Enforcement (LE), and Fisheries patrols, as well as drug interdiction and illegal alien interdiction duties up to 200 miles off shore. The design was developed to meet the operational mission requirements established by the USCG Assistant Commandant for Operations. These requirements included but were not limited to:
- Maximum continuous speed of 25 knots
- Patrol speed not less than 10 knots
- Maneuvering speed not greater than 4 knots with one engine continuously engaged.
- Berthing for any mix of male/female crew members of 10 plus a spare berth
- Based on a Proven Hull Design (parent craft) with at least two years service similar to the duties performed by the existing 82 foot Point class cutters
- Maximum crew comfort consistent with the operational requirements
- Provisions for stores for a crew of 10 for a 5 day mission
Additionally, the vessel was designed in accordance with the American Bureau of Shipping's "Guide of Building and Classing High Speed Crafts" and is capable of towing vessels weighing up to 200 tons. One of the most important design requirements is the necessity to provide a Rigid Hull Inflatable Boat with a launching system that provides for the launch and recovery of the RIB in seas up to 2.5 meter (8 feet) wave height.
|
|
|
|
27.20 m
89' 3"
|
|
|
The "FALSHÖFT" Patrol Boat
Length over all:27.20m
Beam moulded:6.36m
Draught:1.60m
Displacement:71t
Classification:GL + 100 A5 E OC 2 HSDE Patrol Boat ( ) MC Aut
|
|
|
|
31.40 m
103' 0"
|
|
|
Destination:
Vessel is designed for patrol guard and coastguard in territorial waters of Estonia in conditions of high sea. Vessel is assigned for perennial operation in medium sea climate with potential for navigation in small broken discharged ice.
|
|
|
|
66.00 m
216' 7"
|
|
|
|
A&R has been a pioneer In the developmenl of DeepVee hulls which are slate of the art for fast and seaworthy patrol boats. A broad range of designs up to rnini-corvelte size and speeds of 40* knots is available for navies and coastguards.
|
|
