Patrol boat TITAN 249X

outboardrigid hull inflatable boat

Overview
The TITAN hull's special design with multiple integrated angles delivers the stability and manoeuvrability required for interception, pursuit and special operations. The RAPTOR range is available in 8 m, 9 m, 10 m and 11 m lengths and the hull is reinforced for boarding operations. Highly configurable for mission profiles, the platform supports a wide range of mission equipment and layouts.

Configurations

• Delta

Specifications (summary table)
Models: TITAN 249XL (8M) RAPTOR | TITAN 300 (9M) RAPTOR
Overall Length: 26'9" (8.15 m) | 30' (9.14 m)
Overall Beam: 10'4" (3.15 m) | 10'4" (3.15 m)
Overall Draft: 2'10" (87 cm) | 2'11" (89 cm)
Max HP: 600 hp | 700 hp
Speed Range: 50+ knots | 55+ knots
Capacity: 12 persons | 16 persons
Fuel Capacity: 680 Litres | 910 Litres
Dry Weight: 5300 LBS (2405 Kgs) | 7000 LBS (3175 Kgs)
Category Rating: B | B
Configurations: Delta | Delta
Customization: Mission-specific, unlimited options (e.g., self-sealing fuel tanks, shock mitigation seats, varied crew/console layouts)

Technical features

• Model name / series: RAPTOR
• Manufacturer / brand: Titan Boats
• Intended use: Interception, pursuit, military and special operations
• Hull design: TITAN hull with multiple integrated angles for enhanced stability and manoeuvrability
• Available lengths: 8 m, 9 m, 10 m, 11 m
• Typical model variants: TITAN 249XL (8M) RAPTOR; TITAN 300 (9M) RAPTOR
• Overall length: 26'9" (8.15 m) — 249XL; 30' (9.14 m) — 300
• Overall beam: 10'4" (3.15 m)
• Overall draft: ~87–89 cm
• Max engine power: up to 600 hp (249XL) or 700 hp (300)
• Speed: 50+ knots (249XL) / 55+ knots (300)
• Capacity: 12 persons (249XL) / 16 persons (300)
• Fuel capacity: 680 L (249XL) / 910 L (300)
• Dry weight: 5300 lbs (2405 kg) — 249XL; 7000 lbs (3175 kg) — 300
• Category rating: B
• Configurations: Delta
• Customization: Mission-specific, unlimited (e.g., self-sealing fuel tanks, shock mitigation seats, varied crew and console layouts)
