Exterior floodlight JNFL-ATEX-A1-DSeries2

for shipsmarinefor marinas

Short description
ATEX-certified explosion-proof round LED luminaire model JNFL-ATEX-A1-DSeries2, 100 W, 13,500 lm, IP67. Available beam angles: 40°, 60°, 90°, 120°. Colour temperature range: 2200–7000 K. Optional 3-hour emergency back-up battery and 0–10 V dimming. Designed for Zone 1 & 2 hazardous areas.

Mounting & applications

• Ceiling mounting
• Wall mounting (including wall mounting with junction box, 90°)
• Pole pendant and diagonal pole mounting (model D2 only)
• Typical applications: oil & gas, petrochemical, chemical plants, offshore, marine, mining and heavy industry

Product specifications

• SKU: JNFL-ATEX-A1-DSeries2 (100W)
• Power consumption: 100 W
• Total luminous flux: 13,500 lm
• Luminous efficacy: 140 lm/W
• Input voltage: 100–277 VAC; 200–480 VAC; 12–48 VDC
• Input frequency: 50/60 Hz
• Light colour: 2200–7000 K
• LED type: SMD
• Power factor: >0.95
• Color Rendering Index (CRI): >70
• Beam angles: 40°, 60°, 90°, 120°
• Dimming: 0–10 V (optional)
• IK rating: IK08 (glass cover); IK10 with wire guard
• Ingress protection: IP67
• Housing: copper-free aluminium with tempered glass, colour: grey
• Fixture shape & dimensions: Round; 129×270×400 mm
• Net weight: 7 kg
• Operating temperature: -20°C to +45°C; Humidity: 10–95% RH
• Lifespan: 80,000 hours
• Warranty: 5 years
• Temperature class: T6; Gas group: IIC; Zone classification: Zone 1 & 2

Packaging & Shipping

• Product dimensions (mm): 129×270×400
• Net weight: 7 kg
• Export carton dimensions (mm): 400×385×335
• Products per carton: 1
• Export carton gross weight: 9.5 kg

Compliance & standards

• ATEX: II 2 G Ex eb mb IIC T6...T4 Gb; II 2 D Ex tb IIIC T80°C...T100°C Db; additional ATEX codes as specified
• IECEx: Ex eb mb IIC T6...T4 Gb; Ex tb IIIC T80°C...T100°C Db; Ex ec IIC T6...T3 Gc
• UL: Class I Division 2 (Groups A, B, C, D), Class II & III listings
• RETILAP: Esquema 5 RETILAP
• Other: UL1598, UL1598A, UL924, ETL, DLC, ABS, CSA, CB
