Electric windlass
hydraulicfor shipshorizontal

electric windlass
electric windlass
electric windlass
electric windlass
Add to favorites
Compare this product


Characteristics

Operation
electric, hydraulic
Application domain
for ships
Mounting
horizontal
Set-up
above deck
Number of drums
single-drum
Working load

100 kg
(220 lb)

Engine power

55 kW
(75 hp)

Power supply

Max.: 380 V

Min.: 110 V

Chain diameter

64 mm
(3 in)

Anchoring speed

9,000 mm/min
(5.91 in/s)

Description

Classification Certificates:CCS, NK, BV, ABS, DNV-GL, LR, KR, BKI, IRS, RS, Etc. Built as per Classification Rules for sea-going ships. It is a machinery installed on the deck that uses a marine motor to drive an oil pump, a high-pressure oil to drive a hydraulic motor, and a gear box to drive the transmission gear, anchor, sprocket, and axle for anchoring or mooring operations. Its structure is relatively compact, small in size, and cost-effective. Main Technical Specifications: 1. Anchor chain diameter: Φ64mm 2. Rated tension: 175kN 3. Working speed: 9m/min 4. Tether load: 135kN 5. Support load: 982kN 6. Motor power: 55KW 7. Tethering speed: 9m/min 8. Number of anchor sprocket wheels: double anchor 9. Delivery time: 30 days 10. Warranty period: one year after delivery 11. Color: customer specified 12. Power supply: AC single-phase 110V, 220V, 240V AC three-phase 220V, 380V, 440V, 660V 13. Composition: Mainly composed of hydraulic motor, hydraulic oil pump, manual proportional valve, overflow valve, safety valve, base, wall bracket, anchor chain wheel, clutch, brake, cable winch, reducer, electrical control box, double anchor It is composed of brakes, double rollers, etc.
