Stainless steel strainer SFWS-500-02

for boats

Overview
Pump strainer designed for freshwater handling in marine and industrial pump systems. Suitable for installation ahead of pumps, pressure washers or inline piping to trap particulate contaminants.

Application
02 Series strainers are used to filter impurities during transfer of freshwater aboard vessels, in shore-based marina installations and in industrial freshwater circuits. The 316 stainless steel mesh provides high-precision filtration while allowing significant flow rates. Install on the suction or inlet side to prevent blockages and protect pumps, valves and downstream equipment.

Key specifications

• Thread NPT: 1/2" NPT
• Connection: 1/2"
• Filter: 50 mesh (316 stainless steel)

More features & benefits

• Nylon housing for corrosion resistance in freshwater environments
• Thickened PC bowl for improved mechanical resistance
• Internal nylon support prevents mesh deformation under flow
• 316 stainless steel filter provides effective particulate retention
• Compact design allows easy installation and cleaning in confined onboard or shore installations

Dimensions drawing
Refer to the product dimensions image on the original page for mounting and clearance details.

Standard configurations (table)
Model | Filter Specifications | Thread NPT | Connections
SFWS-500-02 | 50 mesh | 1/2" NPT | 1/2"

Technical specifications

• Model: SFWS-500-02
• Filter: 50 mesh (316 stainless steel)
• Thread: 1/2" NPT
• Connection size: 1/2"
• Housing material: Nylon (corrosion-resistant)
• Bowl material: Thickened PC
• Internal support: Nylon
