Boat strainer SFWS-750-03P

stainless steel

Product overview
In-line water strainer designed to protect pumps by removing debris from the intake line. Suitable for installation on suction hoses ahead of the pump in marine and industrial fluid systems.

Models and basic data
Model: SFWS-750-03P / SFWS-750-03
Filter: 20 mesh / 50 mesh
Ports: 3/4" Barb

Summary
The 03 series features a hose-barb connector for quick insertion into 3/4" flexible hose before the pump intake. The stainless steel mesh filter captures particles to prevent pump clogging and prolong service intervals.

FEATURES & BENEFITS

• Stainless steel mesh filter available in 20 mesh and 50 mesh to match filtration needs.
• Hose barb design allows tool-free installation in any orientation; push onto the intake hose.
• Transparent twist-off bowl permits visual inspection of contamination level.
• Removable filter and twist-off bowl enable straightforward cleaning and maintenance.
• Groove-mounted seal ensures proper seating to prevent leaks when assembled.
• Flow direction arrow on the body indicates correct installation orientation.

DIMENSIONS DRAWING
Dimensions drawing available for product sizing reference.

INSTALLATION DRAWING
Installation drawing available showing correct orientation and hose connection method.

STANDARD CONFIGURATIONS
Model | Filter Specifications | Ports
SFWS-750-03P | 20 mesh | 3/4" Barb
SFWS-750-03 | 50 mesh | 3/4" Barb

Technical specifications

• Model numbers: SFWS-750-03P, SFWS-750-03
• Filter options: 20 mesh (SFWS-750-03P), 50 mesh (SFWS-750-03)
• Port size: 3/4" Barb
• Filter material: stainless steel mesh
• Bowl: transparent, twist-off for inspection and cleaning
• Installation: hose barb connector for direct insertion into suction hose; suitable for placement before pump intake in any orientation
• Seal: groove-mounted seal to prevent leaks
• Flow indication: direction arrow on body for correct flow orientation
