Stainless steel strainer SFWS-500-03P

for boats

Product overview
Inline water strainer designed for installation before the pump intake to retain debris and particles, reducing pump blockage and extending pump service life.

Models and key specifications

• Model: SFWS-500-03P / SFWS-500-03
• Filter options: 20 mesh or 50 mesh stainless steel mesh
• Port type: 1/2" Barb

Features & benefits

• Stainless steel mesh captures solids to prevent pump blockage.
• Barb connector enables simple insert-type installation into intake hose in any orientation.
• Transparent bowl allows visual inspection of the filter condition.
• Twist-off bowl and removable filter simplify cleaning and maintenance.
• Seal sits in a dedicated groove to ensure leak-free operation when correctly positioned.
• Flow direction arrow on the body indicates correct installation orientation.

Dimensions & installation
Dimension and installation drawings are available on the product page to ensure correct sizing and mounting.

Standard configurations
Model | Filter Specifications | Ports
SFWS-500-03P | 20 mesh | 1/2" Barb
SFWS-500-03 | 50 mesh | 1/2" Barb

Technical specifications

• Models: SFWS-500-03P, SFWS-500-03
• Filter media: stainless steel mesh (20 mesh or 50 mesh)
• Port type: 1/2" Barb
• Bowl: transparent for visual inspection
• Installation: barb connector for inline installation before pump intake
• Maintenance: twist-off removable bowl and filter for cleaning
• Sealing: seal groove to prevent leaks when seal is correctly seated
• Flow orientation: body marked with direction arrow
• Primary function: prevents debris entering pump intake to extend pump life and reduce repairs
