Water-jet outboard engine Geo-Spot GPS 80/78

electricfor boatfor kayaks

Overview
The Watersnake Geo-Spot GPS 80 lb 78\" bow-mount trolling motor combines 80 lb of thrust with advanced GPS navigation for precise station-keeping, automated route following and improved trolling control. Saltwater-ready, it includes a GPS Nav Sensor (magnetometer, accelerometer, gyroscope), a fibre-reinforced nylon weedless 3‑blade propeller (94 mm pitch), upgraded bracket and turning box, and is operable via handheld remote or optional foot controller. Designed for 24V battery systems including LiFePO4.

GPS FEATURES

• Anchor Mode - Hold position at the press of a button.
• Jog Function - Move the boat in small increments while remaining in Anchor Mode (documented at 1.5 m and referenced at ~1 m increments).
• Cruise Mode - Maintain ground speed regardless of wind or current.
• Pilot Mode - Maintain heading regardless of wind or current.
• Track Recording - Record favourite routes for automatic retracing.
• Navigate Mode - Autonomously navigate to start/end of a route and follow it.

Features

• Remote Control - Handheld remote provides full operation from anywhere on the boat.
• GPS Nav Sensor Included - Adds magnetometer, accelerometer and gyroscope to improve navigation and enable the Jog function.
• Variable speed - Smooth, adjustable motor control.
• Built-in protection - Integrated voltage, current and overheating protection.
• Strong fibre-reinforced nylon weedless 3-blade propeller - 94 mm pitch.
• Upgraded bracket design - Improved usability and longevity.
• Upgraded turning box - Smoother, faster turning performance.
• Saltwater-ready - Sacrificial anode and stainless steel elements.
• Foot controller compatible - Optional foot controller available separately.
• 24V battery system - Designed for 24V systems including LiFePO4.
• Composite main shaft - Now offered as a light, strong composite (listed as epoxy/composite).

Navigation & Track Capabilities

• Record tracks up to 5 km and store up to 16 tracks for autonomous retracing.

Notes on Operation
The GPS Nav Sensor improves Anchor Mode stability and accuracy, enables Jog functionality and enhances overall navigation and tracking. Primary functions are controllable from the handheld remote; an optional foot controller can also be used. The motor is intended for 24V battery systems, including LiFePO4 types.

Technical Specifications

• Model family: Geo-Spot GPS
• Thrust: 80 lb
• Shaft length / type: 78\" epoxy / composite main shaft
• Recommended battery system: 24V (supports LiFePO4)
• Propeller: Fibre-reinforced nylon, 3-blade, 94 mm pitch
• GPS Nav Sensor: included (magnetometer, accelerometer, gyroscope)
• GPS functions: Anchor Mode, Jog Function, Cruise Mode, Pilot Mode, Track Recording, Navigate Mode
• Track memory: up to 16 tracks, each up to 5 km
• Protection: built-in voltage, current and overheating protection
• Mount type: Bow mount
• Saltwater protection: sacrificial anode; stainless steel elements
• Control: Handheld remote (included); optional foot controller compatible
• Upgrades: upgraded bracket design; upgraded turning box
• Propulsion: variable speed
• SKU / EAN: 9312327844672
