Water-jet outboard engine Stealth X

electricfor boatfor kayaks

Overview
The Watersnake Stealth X series is a bow-mount electric trolling motor designed for anglers and small craft operators who need precise positioning and reliable thrust. Built for both saltwater and freshwater use, Stealth X integrates satellite-based Anchor Mode to hold position automatically, plus robust construction for prolonged marine operation.

Navigation and positioning
Equipped with a tri-band GPS antenna (GPS, GLONASS, BeiDou) for enhanced satellite coverage, faster signal acquisition and improved spot-lock accuracy, enabling reliable anchoring in wind and current.

Hardware upgrades
Upgraded mounting bracket for smoother deployment and stowing, reducing physical effort. Reinforced gearing and a stronger drive system deliver faster, more authoritative turning and improved heading control.

Features

• Anchor Mode (spot-lock): automatic boat-hold using satellite positioning at the press of a button.
• Optional navigation sensor: plug-in sensor available to enhance responsiveness and heading accuracy (sold separately).
• Saltwater ready: composite shaft, encapsulated driver module and sacrificial zinc anode for corrosion protection.
• Wireless handheld remote: control speed and steering from anywhere on board.
• LiFePO4 compatible: supports 12V models in use up to 14.5V with built-in voltage protection.
• Anderson plug connections: marine-grade plug-and-play connectors for quick setup.
• Digital speed control: precise forward and reverse speed regulation with smooth power delivery.
• Weedless 3-blade propeller and stainless steel propeller shaft for reduced fouling and corrosion resistance.
• Foot controller compatible: works with optional Gen 3 Foot Controller (sold separately).

User manuals and documentation
Instruction manual, parts list and schematics are provided for the Stealth X series. Service and troubleshooting documentation available for bow-mount motors.

Technical specifications

• Brand: Watersnake
• Model family: Stealth X
• Thrust: 65 lb
• Nominal voltage: 12 V (protected up to 14.5 V)
• Shaft lengths available: 66" (167 cm) and 54" (137 cm)
• GPS: tri-band antenna (GPS, GLONASS, BeiDou)
• Anchor Mode: satellite-based spot-lock (built-in)
• Propeller: weedless 3-blade
• Propeller shaft: stainless steel
• Mounting: upgraded bow-mount bracket for smoother deployment/stowing
• Connectors: Anderson plug marine-grade
• Protection: built-in voltage protection/internal protection circuitry
• Saltwater features: composite shaft, encapsulated driver module, sacrificial zinc anode
• Optional accessories: navigation sensor (plug-in), Gen 3 Foot Controller (sold separately)
