Thermometer multi-purpose instrument VMH Flex

speed displayspeed logcompass

Product description
Compact vessel instrument to display multiple navigation and engine parameters in a small footprint.

Key information

• Series: VMH
• Function: Rudder, Trim, Speed, Engine revolution, Engine hours, Fuel level, Fresh water level, Waste water level, Coolant temperature, Oil temperature, Engine oil pressure, Transmission oil pressure, Boost pressure, Depth, Clock, Compass, Battery
• Nominal Voltage: 24V, 12V
• Bezel Color: Stainless Steel
• Screen dimension: 1.44"
• Connectivity: NMEA 2000, LIN, AirWave Ready

Highlights

• Up to 5 scrollable screens in single or dual layout
• Laser touch-button operable with gloves and in wet conditions
• NMEA 2000® connectivity
• 2x analog resistive inputs for direct sensor connections
• Embedded analog to NMEA 2000® converter
• LIN port for Intelligent Battery Sensor

All features

• Nominal voltage: 12 / 24 V
• Operating voltage: 9 - 32 V
• Protection class: IP x7
• Dimensions: 60 mm (outer) / 52 mm (mounting hole)
• Display: 1.44" sun-readable color TFT display
• Resolution: 125 x 125 pixels
• Analog inputs: 1x resistive / 1x frequency
• Connector: Molex MX150 – 8 Pole / Micro-C M12 5 Pin
• Digital ports: NMEA 2000, LIN bus
• Wireless interface: AirWave Ready

Detailed information
Small-footprint unit designed to present extensive boat data on a compact screen. The laser touch-button enables navigation through up to 5 customizable screens in typical deck conditions.

Each screen can be configured to show priority parameters and alarms. Setup and configuration, including alarm thresholds, can be performed via smartphone with a simple tap.

Technical specifications

• Nominal voltage: 12 / 24 V
• Operating voltage: 9 - 32 V
• Protection class: IP x7
• Dimensions: 60 mm (outer) / 52 mm (mounting hole)
• Display: 1.44" sun-readable color TFT display
• Resolution: 125 x 125 pixels
• Analog inputs: 1x resistive / 1x frequency
• Connector: Tyco / Hirschmann MQS connector 8 pin / Micro-C M12 5Pin
• Digital ports: NMEA 2000, LIN bus
• Wireless interface: AirWave Ready
