Speed display multi-purpose instrument VMH Flex - J1939

compassecho sounderfor boat

Overview
Compact marine multifunction display for monitoring engine and boat data with SAE J1939 connectivity.

Product description
The VMH Flex presents extensive boat and engine information in a compact 60 mm housing. The innovative laser touch-button operates reliably with gloves and in wet conditions, allowing navigation across up to five customizable screens. Setup, alarms and screen configuration are managed easily via smartphone.

Functions

• Rudder
• Trim
• Speed
• Engine revolution
• Engine hours
• Fuel level
• Fresh water level
• Waste water level
• Coolant temperature
• Oil temperature
• Engine oil pressure
• Transmission oil pressure
• Boost pressure
• Depth
• Clock
• Compass
• Battery

Highlights

• Up to 5 scrollable screens in single or dual layout
• Innovative laser touch-button reliable in practical marine conditions (gloves, wet)
• SAE J1939 connectivity
• 2x analog inputs for direct sensor connections
• LIN port for Intelligent Battery Sensor

Connectivity & Inputs

• Digital ports: J1939, LIN bus
• Wireless interface: AirWave Ready
• Analog inputs: 1x resistive / 1x frequency (2 analog inputs in highlights)
• LIN port for Intelligent Battery Sensor

Physical & Electrical

• Series: VMH
• Article Number: B00127801
• Nominal Voltage: 12 V / 24 V
• Operating Voltage: 9 - 32 V
• Protection class: IP x7
• Bezel Color: Stainless Steel
• Dimensions: 60 mm (outer) / 52 mm (mounting hole)
• Screen dimension: 1.44″
• Display: 1.44″ sun-readable color TFT display
• Resolution: 125 x 125 pixels
• Connector: Tyco / Hirschmann MQS connector 8 pin

Caractéristiques / spécifications techniques

• Nominal voltage: 12 / 24 V
• Operating voltage: 9 - 32 V
• Protection class: IP x7
• Dimensions: 60 mm (outer) / 52 mm (mounting hole)
• Display: 1.44″ sun-readable color TFT display
• Resolution: 125 x 125 pixels
• Analog inputs: 1x resistive / 1x frequency
• Connector: Tyco / Hirschmann MQS connector 8 pin
• Digital ports: J1939, LIN bus
• Wireless interface: AirWave Ready
