Inboard engine S16R2-T2MPTAW
propulsiondieselprofessional vessel

inboard engine
inboard engine
inboard engine
inboard engine
inboard engine
inboard engine
Add to favorites
Compare this product


Characteristics

Type
inboard, propulsion
Power source
diesel
Market
professional vessel, for ships
Technology
turbocharged, direct fuel injection
Cooling system
water-cooled
Pollution control standard
Tier 2
Other characteristics
4-stroke
Power

1,450 kW, 1,600 kW, 1,885 kW (1,971.5 hp)

Number of cylinders

16 unit

Displacement

80 l (21 gal)

Engine speed

1,350 rpm, 1,400 rpm, 1,500 rpm (8,482 rad.min-1)

Bore

170 mm (6.7 in)

Stroke

220 mm (8.7 in)

Length

2,946 mm (116 in)

Width

1,525 mm (60 in)

Height

2,030 mm (80 in)

Weight

7,750 kg (17,086 lb)

Description

The S16R2-T2MPTAW engine is designed and built in Japan and finished to customer specifications in France in order to deliver performance and reliability. From the combustion chamber design to the fuel injection technology, to the turbocharger and the advanced cooling system. Everything has been perfectly balanced to provide highly reliable operation, optimum fuel consumption and minimized installation footprint. Utilizing a long-stroke block with in-house MHI turbocharger technology, we have managed to maintain the footprint of our lower output engines, while substantially increasing the power output. Its maintenance is easy as each cylinder has its own cylinder head, and the engine has large inspection covers on the crankcase. This strength and reliability are ideally suited for propulsion for various types of vessels. Benefits: Reliable Compact in size Economical fuel consumption Commonality of parts across the MHIET engine models, simplifies spare part management Applications: Cargo Tanker Tug Cylinder configuration - 16/60°V Flywheel and housing - SAE 21 / SAE 00 Compression ratio - 14.0:1 Cooling method - separate high and low temperature cooling circuit; charge air cooler by closed freshwater system controlled by thermostat (intercooler)
