Digital tachometer PULSAR
for boatsblack230 V

digital tachometer
digital tachometer
digital tachometer
Add to favorites
Compare this product


Application domain
for boats
230 V


This indicator has been designed for detecting the number of revolutions by proximity with the application of a single notch on the moving shaft. It is ideal for measuring the rpm of engines in the automation and marin Reading points: 99999 • Display: 5 digits, 13 mm red Led • Accuracy: ±0,1 rev/min • Temperature stability: 75 ppm (typ.) 100 ppm (max) • Time base: one second quartz scan • Standard power supply (A): 230 Vac (50…60Hz) and 9…28 Vdc • Optional power supply (B): 115 Vac and 9…28 Vdc • Connection: screws on removable terminal block, sect. max 2,5 mm² • Decimal point: activated/disactivated from terminal • Display brightness: dimmable from terminal • Operating temperature: 0…+45°C • Casing: black polycarbonate • Dimensions: 48 x 96 x 105 (112) mm • Front protection class: IP40
