Marine clamcleat CL26 series

opennylon

Description
The ridged 'V' groove design grips rope securely without moving parts and allows immediate release with a short upward and backward pull. Line tensioners lock lines reliably and resist being shaken loose even in demanding marine conditions. Units are simple to rig: push up to tension and secure; pull lines apart to release. Suitable for marine rigging, awnings, tarpaulins and general line control; operable with thick mitts or gloves.

Available variants

• Part No: CL260 — Clamcleat 5mm Line-Lok Black. Colour/Finish: Black
  Hole Spacing: 10 MM
  Length: 31 MM
  Material: Nylon
  Rope Diameter: 2-5 MM
  Unit: PACK 8
• Part No: CL260G — Clamcleat 5mm Line-Lok Glow-in-the-Dark. Colour/Finish: Glow-in-the-Dark
  Hole Spacing: 10 MM
  Length: 31 MM
  Material: Nylon
  Rope Diameter: 2-5 MM
  Unit: PACK 8
• Part No: CL260K — Clamcleat 5mm Line-Lok Khaki. Colour/Finish: Khaki
  Hole Spacing: 10 MM
  Length: 31 MM
  Material: Nylon
  Rope Diameter: 2-5 MM
  Unit: PACK 8
• Part No: CL260NG — Clamcleat 5mm Line-Lok NATO Green. Colour/Finish: NATO Green
  Hole Spacing: 10 MM
  Length: 31 MM
  Material: Nylon
  Rope Diameter: 2-5 MM
  Unit: PACK 8
• Part No: CL260W — Clamcleat 5mm Line-Lok White. Colour/Finish: White
  Hole Spacing: 10 MM
  Length: 31 MM
  Material: Nylon
  Rope Diameter: 2-5 MM
  Unit: PACK 8
• Part No: CL266 — Clamcleat 3mm Mini Line-Lok Black. Colour/Finish: Black
  Hole Spacing: 7 MM
  Length: 21.3 MM
  Material: Nylon
  Rope Diameter: 1-3 MM
  Unit: PACK 12
• Part No: CL266G — Clamcleat 3mm Mini Line-Lok Glow-in-the-Dark. Colour/Finish: Glow-in-the-Dark
  Hole Spacing: 7 MM
  Length: 21.3 MM
  Material: Nylon
  Rope Diameter: 1-3 MM
  Unit: PACK 12
• Part No: CL266K — Clamcleat 3mm Mini Line-Lok Khaki. Colour/Finish: Khaki
  Hole Spacing: 7 MM
  Length: 21.3 MM
  Material: Nylon
  Rope Diameter: 1-3 MM
  Unit: PACK 12
• Part No: CL266NG — Clamcleat 3mm Mini Line-Lok NATO Green. Colour/Finish: NATO Green
  Hole Spacing: 7 MM
  Length: 21.3 MM
  Material: Nylon
  Rope Diameter: 1-3 MM
  Unit: PACK 12
• Part No: CL266W — Clamcleat 3mm Mini Line-Lok White. Colour/Finish: White
  Hole Spacing: 7 MM
  Length: 21.3 MM
  Material: Nylon
  Rope Diameter: 1-3 MM
  Unit: PACK 12

Technical specifications

• Operating principle: Ridged V-groove grips rope; immediate release by a short upward and backward pull; resists being shaken loose.
• Use case: Line tensioner for securing and releasing lines in marine rigging, awnings, tarpaulins and tents; easy to rig and operate even with thick mitts or gloves.
• Materials: Nylon (all listed variants).
• Available hole spacings: 7 MM, 10 MM.
• Available lengths: 21.3 MM (mini), 31 MM (5mm Line-Lok).
• Rope diameter compatibility: 1-3 MM (mini variants), 2-5 MM (5mm variants).
• Colour/finish options: Black, Glow-in-the-Dark, Khaki, NATO Green, White.
• Packaging units: PACK 8 for 5mm Line-Lok variants; PACK 12 for 3mm Mini Line-Lok variants.
• Part numbers / variants: CL260, CL260G, CL260K, CL260NG, CL260W, CL266, CL266G, CL266K, CL266NG, CL266W.
