Boat navigation light 01101-RL

LEDthree-colorred

Product Overview
Compact, battery-powered LED navigation light for small craft, tenders and kayaks. Designed for temporary or backup use, the 01101-RL provides selectable red, green or combined sidelight indication in a portable housing suitable for onboard storage and rapid deployment.

Mounting & Operation
Quick-release nylon rail mount with included gaskets to fit round and square tubing. Push-top switch selects solid red, solid green or combined output to meet COLREGs sidelight requirements when used appropriately.

Key Features

• Multi-Color LED Lighting: 4 × 0.5W "2835" red LEDs and 4 × 0.5W "2835" green LEDs; selectable red, green or combined output via on-off switch.
• Adaptable Mounting: Supplied rail mount and two gaskets for square tubing (1") and round tubing diameters 22 mm, 25 mm and 32 mm.
• Battery Powered: Operates on 3 × AA batteries (not included) for portable, wiring-free use.
• Ingress Protection: IP67 rating for water and dust resistance suitable for marine environments.

Specifications

• Light Color: Red, Green or Combo
• LED Configuration: 4 × 0.5W "2835" Red + 4 × 0.5W "2835" Green
• Material: ABS housing, PC lens, nylon mount
• Power Source: 3 × AA batteries (not included)
• Waterproof Rating: IP67
• Mounting Type: Rail mount (quick-release)

Model Option
item No. | Rail Mount | Light
01101-RL | For square tubing 1" and round tubing 22 mm / 25 mm / 32 mm | Red, Green, Combo
