Courtesy light 00383 series

indooroutdoorfor boat

Product Description
The Series 00383 LED Courtesy Light provides low-profile, marine-grade illumination for decks, stair risers and walkways. Its compact flush-mount housing (Ø100×25 mm) allows neat integration into composite, wood or fiberglass surfaces.
The PC (polycarbonate) body combined with a polished S.S.304 stainless steel trim ring delivers corrosion-resistant performance and an IP67 ingress protection rating for reliable operation in wet or splash-prone environments.
Powered at 12 VDC with a built-in PCB driver, the fixture includes six RGBW LEDs and consumes 0.5 W per cycle, offering energy-efficient lighting and selectable color options suitable for interior and exterior marine applications.

Key Features

• PC housing with polished S.S.304 stainless steel trim ring
• IP67 rated for water and dust resistance
• Compact flush-mount design (Ø100×25 mm) for seamless deck installation
• Six RGBW LEDs with integrated PCB driver
• 12 VDC operation, 0.5 W per cycle for low power draw
• Available color variants: Blue, Daylight White, RGBW

Ordering Information

• 00383-SSBU: Blue — 14 lm (packing: 320/CTN)
• 00383-SSWH: Daylight White — 73 lm (packing: 320/CTN)
• 00383-SSRGBW: RGBW — White: 43 lm / Green: 27 lm / Blue: 7 lm / Red: 7 lm (packing: 320/CTN)

Technical Specifications

• Series: 00383
• Mounting: Flush mount
• Cut-out / Outer dimensions: Ø100 × 25 mm (flush)
• Housing material: PC (polycarbonate)
• Trim ring: Polished S.S.304 stainless steel
• Ingress protection: IP67
• LED configuration: 6 × RGBW LEDs
• Driver: Built-in PCB driver
• Operating voltage: 12 VDC
• Power consumption: 0.5 W per cycle
• Luminous output (by variant): Blue 14 lm; Daylight White 73 lm; RGBW — White 43 lm / Green 27 lm / Blue 7 lm / Red 7 lm
• Packing: 320 units per carton
