Livewell timer 11114
for aerators12 V

Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 2
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 3
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 4
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 5
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 6
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 7
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 8
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 9
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 10
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 11
Livewell timer - 11114 - AAA WORLD-WIDE ENTERPRISES LTD. - for aerators / 12 V - image - 12
Add to favorites
Compare this product
Go to the AAA WORLD-WIDE ENTERPRISES LTD. website for more information

Characteristics

Applications
for aerators, for livewells
Voltage
12 V

Description

Product overview
Keep live bait and onboard livewells aerated while conserving battery power with model 11114. This control center manages 12V aerator and recirculation pumps via a three-position switch (ON / OFF / TIMED) and a digital interface for timed cycles. The front panel is black laser‑engraved on anodized aluminum and is rated IP65 for splash and weather resistance.

Key features
  • Three-position operating switch: ON, OFF, TIMED.
  • Adjustable start/stop times: 1–999 seconds via an easy-to-read digital display.
  • Automatic pump cycling: default run time 30 seconds with adjustable pause intervals from 2 to 5 minutes.
  • Compatibility: for 12V aerator or recirculation pumps; maximum output 10A.
  • Durable enclosure components: IP65 protection and black laser-engraved anodized aluminum panel suitable for marine exposure.


Operating modes
  • ON: Pump runs continuously.
  • OFF: Pump remains off.
  • TIMED: Pump cycles automatically according to programmed start and stop times.


Model options
Item No. | Function
11114 | Adjustable timer with 3P switch

Technical specifications
  • Product Type: Automatic aerator timer control center
  • Operating Modes: ON / OFF / TIMED
  • Rated Voltage: 12V DC
  • Maximum Output: 10A
  • Start/Stop Time Adjustment: 1–999 seconds
  • Timed Pump Operation: 30-second run cycle
  • Pause Adjustment: 2–5 minutes
  • Protection Rating: IP65
  • Panel Finish: Black laser-engraved anodized aluminum
