New NaviLED Trio - High technology for high places
Hella marine introduces the worlds most advanced LED Tri-Colour.
Designed and manufactured in New Zealand, the new state of the art LED navigation lamp provides class leading energy efficiency, reliability and safety.
With an ultra low current draw of <3.5W for Port, Starboard and Stern combined and <1.5W for the anchor function, the power saving benefits are substantial compared to the 25W consumed by incandescent Tri-Colour lamps.
Sophisticated Hella marine Multivolt electronics ensure consistent and safe illumination plus lamp protection under severe voltage fluctuations, low battery voltages and across long cable runs.
The complete light unit mounts on a secure 316 stainless steel shaft via a pre-wired plug and socket for a reliable electrical connection and ultra secure installation. The unique system also allows for a swift and easy removal and re-installation. Lightweight, completely sealed device, impervious to saltwater and contaminants for an ultra long life and reliability at sea.
Advanced Hella marine lens and optics technology ensures visibility and safety at sea with ultra precise horizontal and vertical cut-off angles compared to incandescent lamps, clearly indicating a vessel’s movement and heading. The NaviLED Trio lamp is internationally certified according to BSH, IMO COLREG, USCG and ABYC.
With class leading efficiency, reliability and a user-friendly installation system, the Hella marine NaviLED Trio provides comprehensive features and benefits backed by a 7 year factory warranty.
|
|
These navigation lights belong to the newest generation of lights. They are protected by many patents and characterized by the most intensive light luminosity, clarity of colours, high resolution lenses, innovative patented design and vanguard electronics. It is undoubtedly the best product available in the market in this category. The lights are certified as compliant with the strictest requirements of IMO COLREG 1972 Regulation.
EPLF0010 - GREEN 112.55%u02DA LED Starboard (right) Navigation Light for Boats of %u2264 20 m
EPLF0015 - RED 112.55%u02DA LED Port (left) Navigation Light for Boats of %u2264 20 m
Technical Characteristics
Field of application: boats < 20m
Visibility arc: 112.5°
Input voltage: 9-30Vcc
Luminous source: power red or green LED 1W
Protected against polarity inversion and spike
Equipped with supply cable
Maximum absorbed power: 2W
Impact resistant
Mechanical protection standard: IP56
Average life of the LED: 10.000 hours
Easy to install
|
|
Compact LED navigation lamps. Pre wired and completely waterproof.
- 2 Nautical Mile Visibility
- Long service life
- Impact and vibration proof
- Low power consumption
- Multivolt 8-28V DC
- Approved by: IMO COLREG, USCG, RINA (I), ABYC A-16, NMSC
Available in either Black or White Shrouds, with clear or coloured lens.
|
|
BSH approved LED navigation lights.
Designed and manufactured in New Zealand, NaviLED PRO lamps are a quantum leap forward in energy efficiency and durability.
Combining the latest LED and Multivolt 9-33V DC technology, the NaviLED PRO range have ultra low power consumption, just 10% of that required to run a bulb navigation lamp, just 3.2 watts.
Fully sealed in UV and high impact resistant acrylic, and pre-wired with 2.5m of marine cable, these lamps are IP67 certified making them extremely reliable.
Available in either Black or White shrouds.
|
|
These navigation lights belong to the newest generation of lights. They are protected by many patents and characterized by the most intensive light luminosity, clarity of colours, high resolution lenses, innovative patented design and vanguard electronics. It is undoubtedly the best product available in the market in this category. The lights are certified as compliant with the strictest requirements of IMO COLREG 1972 Regulation.
Technical Characteristics:
Field of application: boats < 20m
Visibility arc: 360°
Input voltage: 9-30Vcc
Luminous source: power white LED 2.5 W
Protected against polarity inversion and spike
Equipped with supply cable
Maximum absorbed power: 3.5W
Impact resistant
Mechanical protection standard: IP56
Average life of the LED: 10.000 hours
Easy to install
|
|
aqua signal 25 STANDARD – robust navigation light of special plastic in black or white
Voltage:
12 V, 24 V
Housing:
Polycarbonate, shock resistant, non-corrosive, non-magnetic, seawater resistant
Protection:
IP 45
Optics:
(Fresnel) plastic
Electric:
2/3 pol.
Range of visibility:
1 nm, 2 nm. (starboard, port, bicolor)
Application vessels:
< 12 m / 39’ (Scandinavia < 7 m / 23’)
Authorisation:
CE, USCG, IMO
|
|
Modern design and optimized size for sport boats and yachts up to 50 m length. 2 LEDs for more color-brightness and double safety. Power consumption. Vibration resistant. Easy installation with waterproofed plug-in connection.
Voltage:
12 – 24 V DC, +/- 20%
Housing:
Polycarbonat in black or white. UV- and saltwater resistant
|
|
Series 32 LED - navigation lights, application vessels < 50 m / 163’, visibility 2 nm / 3 nm, housing and optics non-corrosive, seawater resistant, consumption extremely low
Voltage:
12 V, 24 V
Housing:
Polycarbonate in black or white, shock resistant, non - corrosive, non – magnetic, seawater resistant. The LED-body is thermally connected to a machined aluminium casing which keeps it cool allowing a liftetime of more than 50.000 hours. Optional stainless steel covers available for port-, starbord-, stern- and bicolor lights
Optics:
Patented optics are UV- and saltwater resistant requiring only a single LED per light source
Electric:
Low power consumption (1,5 W per sector). Current from 12 – 24 V. Invers polarity protection
Authorisation:
CE, BSH, USCG, RINA, IMO
|
|
- Standard Flash Pattern - 14, 24, 30, 60 FPM (flashes per minute)
- High-intensity LEDS (no bulbs)
- Efficient solid-state circuitry
- One year warranty
- High impact resistant
- UV stabilizer
- Clear lens
- Water tight
- Replaceable backup batteries last up to 5 years
|
|
Visibility Lights signal your watercraft's position and direction and status to other watercrafts helping to avoid collisions.
Mount the red light on the left or port side and the green light on the right or starboard side. If an approaching watercraft sees the green light, he has the right of way. If the approaching watercraft sees the red light, your watercraft has the right away.
Features:
- Each strip contains 6 ultra-bright LEDs
- All cables and assembly insruction included
- Weather and wake resistant
- LED bulb life is approximately 100,000 hours
- Equipped with double insulated wiring
- Low current draw, 50-70 mA's per light
|
|
- Divide your consumption by 20 !
- Very high efficiency LED lamp
- Very long life: >50,000h @ 25°C (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Very low power consumption: 1.8W typ.
- Current draw: <150mA @ 12VDC / <80mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 360° horizontal / 120° vertical
- Dimensions: Ø 1" x 2.3"
- Available with BA-15S or BA-15D or BAY-15D bayonet base
|
|
- Divide your consumption by 10 !
- Very high efficiency LED lamp
- Very long life: >50,000h (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Power consumption: 1W typ.
- Current draw: <90mA @ 12VDC / <45mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 300° horizontal / 120° vertical
- Dimensions: Ø 0.79"
- Available in lengths: 1.42" / 1.5" / 1.62"
- Pictures and information may be changed or updated without notice
|
|
| ... products without information |
| |
KTR LED - LIFERING BUOY LIGHT
Codice prodotto: EPLA0002
SOLAS MED Directive 96/98/EC as modified by MED Directive 2002/75/EC, Res. IMO MSC 81(70) and CE Approved Lifering-buoy light
Lifering-buoy light KTR LED is approved in compliance with the MED Directive 96/98/EC as modified by MED Directive 2002/75/EC, Res. IMO MSC 81(70) and in compliance with CE requirements (European ship steering wheel) KTR LED is a highly technological and very compact lifering buoy light. Completely watertight, with a compact design , a SMD electronic circuit, KTR LED gives out a very intense flashing light that covers the whole of the upper hemisphere and is equipped with a tip overswitching system by means of a gravity switch. It has an autonomy of more than 18 hours and is battery operated (4 LR6 alkaline batteries 1,5Veach, included).
|
|
|
|
|
|
|
KV LED - LIFERAFT LIGHT
Codice prodotto: EPLE0003
KV LED is one of the most powerful liferaft lights in toady%u2019s market. Its luminous intensity is 4.3 cd, which is greater than 2 mi (3.2 km), and is guaranteed for at least 12 hours. However VK LIGHT will continue to emit light for at least 24 hours in total. KV LED is different from any other lights because instead of bulbs it makes use of LED. The white high power LED used offers additional safety, increases the brightness and ensures its uniform distribution in all directions.
It is one of the most compact and light yet powerful external liferaft lights.
TECHNICAL SPECIFICATIONS
Approval Type - MED Directive96/98/EC as modified by MED Directive 2002/75/EC, Res. IMO MSC.81(70)
Material - UV stabilized composite polymer
Beam Angle - All directions of the upper hemisphere
Luminous Intensity - 4.3 cd, greater than 2 mi (3.2 km)
Activation - Pull activation
Lamp Type - White high power LED
Battery Type - Lithium %u2013 5-year replacement life (10-year storage life)
Operational Life 12 hours minimum at -30%u02DAC (-22%u02DAF) to +65%u02DAC ( 149%u02DAF)
Limited Warranty 1 year
* SIC Divisione Elettronica manufactures customized versions %u2013 OEM solutions - of internal and external liferaft lights as well.
|
|
Very bright SOLAS constant light, 2 h capacity, automatic activation after righting into floating position, stable waterproof and buoyant housing, droptested to 35 m, with holder.
Emergency lights mean playing an active role in your safety - they greatly improve your chances of being discovered in an emergency situation.
|
|
| ... products without information |
| |
|
|
