Diesel generator set W-GV 1 Scalino

for boatssoundproofedwith alternator

The most silent and compact generator in the market! 1-cylinder Permanent Magnet generator with external DC PowerCube 2.8 kW continuous 24 VDC or 48 VDC power from your programmable speed generator system High efficiency and strong peak power Saving fuel and ensuring smooth running of your genset Genverter Power, the best choice for your energy supply Also available with Stainless steel enclosure for installation outside the vehicle MAIN SPECIFICATIONS System output - 2.8 kW Charge current - 80 A at 24 VDC or 40 A at 48 VDC DC Charge module - PMG Harmonic distortion - < 5% ALTERNATOR SPECIFICATIONS Type - Permanent Magnet Alternator (PMA) RPM range - 2800...3200 SPECIFICATIONS DIESEL ENGINE Engine model - WhisperPower WP1 Number of cylinders - 1 Capacity - 309 cc Engine cooling - Radiator cooling Fuel consumption - 0.8 ... 1.2 l/hr Starting - Electrical (12 V) Starter battery - 12 V - 55 Ah (optional) 12 V Battery charger - Included DIMENSIONS & WEIGHT Length - 430 mm Width - 450 mm Height - 510 mm Dry weight - 73 kg Length PMG - 420 mm Width PMG - 196 mm Height PMG - 148 mm Weight PMG - 7 kg
