Flexible solar panel eMarvel 40w walkable
for boatscustom

flexible solar panel
flexible solar panel
flexible solar panel
flexible solar panel
flexible solar panel
flexible solar panel
Add to favorites
Compare this product


Other characteristics
for boats, custom
Peak power (Wp)

40 W

Voltage at maximum power

18.6 V

Max power current (Imp)

2.2 A

Open circuit voltage (Voc)

21.9 V

Short circuit current (Isc)

2.3 A


1.1 kg
(2.4 lb)


440 mm
(17 in)


580 mm
(23 in)


5 mm
(0 in)


40w flexible solar panel has rigid surface and material,it's for flat surface installtion Framelss,thin without aluminium frame Max bend angle 5degree Walkable and anti skids surface,resistance to hailstone,pressure and longivity. CE ROHS SGS IEC certified Advantage of eMarvel marine solar panel High efficiency solar cell AHONY uses leading brand cell and high efficiency A grade quality to insure high and stable output. Walkable and Anti-slippery By any means and do not damage cells,the rough antislippery surface is safer for installation or maintenance. The surface material resists high temperature Flame retardancy UL94 VTM-0.Rugged and insulated bottom reduces area touched surface of yacht,RV,cart etc.Enables air circulation,it cools down panel and get little power loss. Rigid,thin,light design for widely use It’s rigid to resist hailstone,semi flexible with bend angle less 5 degree,suitable for off grid use,marine,yacht,RV roof,on grid home system,parking lot,portable power generator etc. It’s 1/6 thickness 7/10 the weight of glass solar panel. Model No. - eMarvel 40w Product Name - semi rigid marine solar panel Maximum Power[Wp] - 40 Solar Cell - back contact solar cell or mono PERC Cell Array[Pcs] - 2*16 Cell Efficiency - 23.70% Size[mm] - 440*580*5 Max Power Voltage Vmp[V] - 20.88 Max Power Current Imp[A] - 1.92 Open Circuit Voltage Voc[V] - 24.64 Short Circuit Current Isc[A] - 2.07 Net.Weight[kg] - 1.8 Power tolerance[ - ±5% NOCT[ - 45±2 Operating Temperature[ - -40/+85 Temperature Coefficient Pmax[%/K] - -0.3 Temperature Coefficient Voc[[%/K] - -1.74mV Temperature Coefficient Isc[[%/K] - 0.05 Maximum System Voltage[V] - 1000 V
