Outboard express cruiser 435 LXF Li-Ion

four-enginestepped hullhard-top

Overview
The 435 LXF Li-Ion S-Class is the newest LXF lineup introduction. It is designed around a Fathom e-Power lithium ion battery management system (no generator necessary); these batteries are also charged by the Mercury engines. The model pairs high-performance hull technology with premium, meticulously crafted carbon-infused construction and a sophisticated blend of appointments and technologies suitable for luxury boating.

Key features

• Fathom e-Power lithium ion battery management system (Li-Ion) – no generator required.
• Batteries charge via Mercury engines.
• Carbon Epoxy Construction (Carbon Fiber/E-Glass used in epoxy infusion process).
• Dual Scout Stepped Hull Technology for high performance and ride quality.
• S-Class designation for highest level of finish (applies to models 33' and up).
• Loaded with an abundance of standard features and a wide array of optional equipment.
• Price example on site includes standard boat, standard engines, and standard Seakeeper gyro (see local dealer for availability and details).

Quick specifications
Length: 43 ft 4 in (13.2 m)
Beam: 13 ft 1 in (3.99 m)
Fuel Capacity: 605 gal (2,290 L)
Max HP: 1,800 HP (1,342.9 kW)
Draft (approx): 28 in (0.71 m)

Additional specifications

• Freshwater Tank: 66 gal (250 L)
• Cabin Headroom: 6 ft 6 in (1.98 m)
• Dry Weight w/o Engines (approx): 17,450 lbs (7,915 kg)
• Waste Capacity: 17 gal (64 L)
• Aft Fish Box Port / Stbd: 2 x 120 gal (454 L each)
• Head Standing Room Height: 6 ft 3 in (1.91 m)
• Deadrise: 22 degrees
• Dry Weight w/ Twin Mercury 600's (approx): 21,250 lbs (9,638.84 kg)
• Dry Weight w/ Quad Mercury 425's (approx): 21,510 lbs (9,767.77 kg)
• Baitwell Capacity: 2 x 26.5 gal (100 L each)
• Berth Sleeping Length: 7 ft 2 in (2.84 m)

Model description / design notes
Designed as an S-Class luxury center console, the 435 LXF Li-Ion emphasizes performance, hull technology and high-end carbon-infused structural construction. The combination of lightweight, high-strength Carbon Epoxy Construction and Scout’s stepped hull technology aims to deliver refined handling, improved efficiency and premium onboard comfort and amenities.

Caractéristiques / spécifications techniques

• Model: 435 LXF Li-Ion
• Length Overall: 43 ft 4 in (13.2 m)
• Beam: 13 ft 1 in (3.99 m)
• Draft (approx): 28 in (0.71 m)
• Fuel Capacity: 605 gal (2,290 L)
• Max HP: 1,800 HP (1,342.9 kW)
• Freshwater Tank: 66 gal (250 L)
• Waste Capacity: 17 gal (64 L)
• Dry Weight (w/o engines approx): 17,450 lbs (7,915 kg)
• Dry Weight (w/ Twin Mercury 600's approx): 21,250 lbs (9,638.84 kg)
• Dry Weight (w/ Quad Mercury 425's approx): 21,510 lbs (9,767.77 kg)
• Cabin Headroom: 6 ft 6 in (1.98 m)
• Head Standing Room Height: 6 ft 3 in (1.91 m)
• Deadrise: 22 degrees
• Aft Fish Box Capacity: 2 x 120 gal (454 L each)
• Baitwell Capacity: 2 x 26.5 gal (100 L each)
• Berth Sleeping Length: 7 ft 2 in (2.84 m)
• Construction: Carbon Epoxy (Carbon Fiber / E-Glass epoxy infusion)
• Battery System: Fathom e-Power lithium ion battery management
• Engines: Mercury (battery charging capability noted)
