Tender davit Seatenderhydraulicmultifunctionstainless steel
Add to favorites
Compare this product
Characteristics
- Application domain
- tender
- Operation
- hydraulic
- Type
- multifunction
- Material
- stainless steel
- Other characteristics
- swim platform
- Lifting capacity
Min.: 400 kg
(882 lb)Max.: 2,000 kg
(4,409 lb)- Height
1,050 mm
(41 in)- Length
1,340 mm
(53 in)
Description
Product overview
Capacity
'Simple' model
'Premium' model
Shipyard and installation notes
Technical specifications
- Multifunctional hydraulic tenderlift for stern/swim platforms, designed for launch and recovery of tenders and PWCs and for expanding bathing or lounge areas.
- Mounted on the vertical transom surface; constructed in AISI 316L (marine-grade stainless steel) for corrosion resistance.
- Design reduces constant submersion of wear-prone components to extend service life of cylinders and sliding/rotating parts.
- Innovative adjustment system simplifies installation and allows precise height and tilt regulation at the attachment base and platform.
Capacity
- Standard lifting capacities from 400 kg to 2000 kg (880–4410 lbs).
- Custom capacities and bespoke designs available on request to suit different tenders and vessel requirements.
'Simple' model
- Lightweight, compact design for secure onboard integration and compatibility with most hulls.
- Quick vertical adjustment with millimetric regulation and platform tilting for fine positioning.
- Essential configuration with available optional accessories for specific needs.
'Premium' model
- Advanced solution for a clean, secure installation with regulation options before and after mounting.
- Direct connection between cylinders with inverse plunger arrangement to optimize space and wiring routing.
- Hydraulic ram cylinders equipped with locking valves to secure platform position during navigation.
- Quick vertical adjustment and precise tilting with millimetric control.
Shipyard and installation notes
- Flexible mounting reduces the need for pre-machining the transom when it is not perfectly vertical on the Y axis.
- Installation-friendly features simplify on-site adjustments and wiring layout.
- Additional options and custom integrations available to meet specific vessel or shipyard requirements.
Technical specifications
- Material: AISI 316L (marine-grade stainless steel).
- Mounting: vertical transom / stern hull mounting.
- Type: hydraulic tenderlift for stern/swim platform.
- Lifting capacity (standard): 400 kg – 2000 kg (880 – 4410 lbs); customizable on request.
- Models: 'Simple' and 'Premium'.
- Hydraulic cylinders with locking valves to secure position during navigation.
- Inverse plunger arrangement for compact installation and optimized wiring routing.
- Millimetric vertical adjustment and platform tilting with quick-setting mechanisms.
- Design minimizes constant submersion of wear-prone parts to extend service life.
- Custom capacities, designs and additional options available on request.
VIDEO
Catalogs
SEATENDER
7 Pages
