Depth transducer PM111LM
water temperatureacousticfor boat

depth transducer
depth transducer
depth transducer
depth transducer
Add to favorites
Compare this product


Measured value
depth, water temperature, acoustic
Application domain
for boat
Other characteristics
ultrasonic, CHIRP


Having the right tool for the job makes the job easier and gives better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2 kW, low to medium-frequency transducer. The Chirp-ready PM111LM delivers the deep-water performance of the low frequency down to 1,829 m (6,000') plus the detail-delivering returns produced by the narrower beams of the medium band. Chirp technology delivers 5 to 10 times-greater detail and resolution than conventional frequencies. This transducer delivers up to 87 kHz of total bandwidth in a single installation. The PM111LM transmits across the following bandwidths: Low frequency 38 to 75 kHz, Medium frequency 80 to 130 kHz Features Depth and fast-response water-temperature sensor 2 kW Low frequency: 38 to 75 kHz 19° to 10° port-starboard beamwidth 10° to 5° fore-aft beamwidth Depth performance to 1,829 m (6,000') Medium frequency: 80 to 130 kHz 13° to 8° beamwidth Depth performance to 914 m (3,000') 87 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 38, 50, 88, and 107 kHz plus everything else in the bandwidth Urethane housing designed for a custom pocket/keel mount Also available as in-hull (R111LM) and external (R109LM) mounts Exclusive Xducer ID® technology
