Depth transducer PM111LH
water temperatureacousticfor boat

depth transducer
depth transducer
depth transducer
depth transducer
Add to favorites
Compare this product


Measured value
depth, water temperature, acoustic
Application domain
for boat
Other characteristics
ultrasonic, CHIRP


The PM111LH is a pocket/keel mounted, 2 kW transducer which delivers excellent target resolution, bottom discrimination, and bait and game-fish separation. The PM111LH is packed with a fifteen-element, low-frequency array that operates anywhere between 38 and 75 kHz, delivering great depth capabilities down to 1,829 m (6,000'). The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow (8° to 4°) beam that provide tremendous bottom detail and fish-target discrimination at depths to 457 m (1,500'). Features Depth and fast-response water-temperature sensor 2 kW Low frequency: 38 to 75 kHz 19° to 10° port-starboard beamwidth 10° to 5° fore-aft beamwidth Maximum depth of 1,829 m (6,000') High frequency: 130 to 210 kHz 8° to 4° beamwidth Maximum depth of 457 m (1,500') 117 kHz of total bandwidth from one transducer Covers popular fishing frequencies of 50, 60, and 200 kHz plus everything else in the bandwidth Urethane housing designed for custom pocket/keel mounting Also available as in-hull (R111LH) and external (R109LH) mounts Exclusive Xducer ID® technology Specifications Weight: 13.6 kg (30 lb.) Recommended Boat Length: 8 m (25') and above Hull Material: Solid fiberglass only Hull Deadrise: Accommodates any deadrise angle based on custom cavity construction Acoustic Window: Urethane 16 internal broadband ceramic assemblies
