ヨット用ヨットオーニングポール INT157

ボート用ステンレス製

Extendable Boat Bimini System

Enjoy shade on board and make the most of your time on your boat with our extendable bimini system. Ideal for small, medium, and sailing boats.

Easy Installation in a Few Steps

Ideal for boats that have only a small canopy or bimini over the central console. The kit allows you to extend the shaded area towards the bow or stern depending on your needs.

System Benefits

• Quick bimini extension without complicated installation
• Adjustable telescopic tube with 6 positions (up to 190 cm)
• Compatible with boats with or without railings
• Materials resistant to water and marine conditions
• Optional custom-made fabric in white or blue
• Quiet system thanks to anti-vibration bushings

Available Models
Kit for Boats with Railings — Includes:

• 2 stainless steel telescopic tubes (110–190 cm / Ø 25 mm)
• Fabric strap and carabiner
• 2 quick-release hinges for railing installation

Article / Railing Diameter (for railing kits)
5300 — 22 mm
5301 — 25 mm
5302 — 30 mm

Kit for Boats without Railings — Includes:

• 2 stainless steel telescopic tubes (110–190 cm / Ø 25 mm)
• Fabric strap and carabiner
• Installation sleeves (vertical or angled)

Article / Installation Type (for deck sockets)
5305 — Straight (vertical)
5310 — Angled 60°

Bimini Fabric (Optional – Custom Made)

The fabric is not included in the kit. We can manufacture the fabric to your specifications after the system is installed to ensure a perfect fit. Available examples: reinforced rectangular fabric in White (article 5340) or Blue (article 5341), priced per m².

3-Step Installation

• Attach the supports or sleeves to the railing or deck
• Insert the telescopic poles
• Extend and secure the fabric using the included straps and carabiners

Notes

• Supports and installation sleeves include plastic bushings to prevent noise from the poles
• Stainless steel components are V4A / 316 suitable for marine conditions

Caractéristiques / spécifications techniques

• Diameter options: Deck socket inclined, Deck socket vertical, for 22 mm rail tubes, for 25 mm rail tubes, for 30 mm rail tubes
• Material: Stainless steel V4A (316)
• Weight: 2,9 kg
• Telescopic tube length: 110–190 cm (6 positions)
• Tube outer diameter (poles): Ø 25 mm
• Bimini fabric: not included (custom-made to order, available white or blue, price per m²)
• SKU: INT157
• Price range shown on page: EUR 354.82 – EUR 575.79
