NEW * NEW * NEW
Compact, economical and quiet - very easy to operate and the best price-performance ratio. But above all, high water- and outstanding components-quality. Enjoy a new independence and improved safety on board. The AQUAGIV SILVER SERIES.
Small - lightweight - compact
The new SILVER SERIES finds himself place even in tiny spaces. Since everything has already been pre-assembled, installation is easy and quick.
Processor control
The constant monitoring of salinity, the constant monitoring of operating conditions and the fully automatic flush - even in your absence: the control of the new SILVER SERIES is child's play, and relieves the user of almost all the work.
Remote control
The optional remote control allows you an easy control and monitoring from a different place. Keep the track.
New salinity sensor ACS01
In the search for technical solutions that are very reliable, AQUAGIV goes new ways: with the new - in-house developed and produced salt sensor that monitors water quality throughout the production. Only wholesome water reaches your tank.
High pressure pump unit
The heart of a desalination plant is the high-pressure unit. It must be able to produce up to 60 bar pressure and cope durable with the aggressive medium saltwater. Therefore the new AQUAGIV Watermaker comes with the Danfoss pump consisting of duplex and super duplex stainless steel, whose lifetime is at least 8000 hours without maintenance. Annoying oil changes are eliminated completely.
|
|
A wide output range is able to satisfy all needs. Modular systems are ideal for heavy use, even in severe conditions.
Watermaker MODULAR 30M12-24 35 lit/h :
Watermaker group dimensions: L= 68 D= 22 H= 30 cm.
Pump group dimension L= 34 D= 19 H= 35 cm.
Weight: 31 Kg
Consumption: 100 Watt (8A @ 12 VDC)
Power supply: 12 or 24 VDC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
Affordable, light and easy to install, SMART is the ideal solution for those who prefer a simple and essential system.
Watermaker SMART 30S12-24 30 lit/h :
Watermaker group dimensions: L= 68 D= 24 H= 24 cm.
Pump group dimension L= 34 D= 19 H= 35 cm.
Weight: 25 Kg
Consumption: 110 Watt (9A @ 12 VDC)
Power supply: 12 or 24 VDC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
A wide output range is able to satisfy all needs. Modular systems are ideal for heavy use, even in severe conditions.
Watermaker MODULAR 60M12-24 60 lit/h :
Watermaker group dimensions: L= 68 D= 31 H= 30 cm.
Pump group dimension L= 34 D= 19 H= 35 cm.
Weight: 38 Kg
Consumption: 240 Watt (20A @ 12 VDC)
Power supply: 12 or 24 VDC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
Affordable, light and easy to install, SMART is the ideal solution for those who prefer a simple and essential system.
Watermaker SMART 60S12-24 60 lit/h :
Watermaker group dimensions: L= 118 D= 25 H= 30 cm.
Pump group dimension L= 34 D= 19 H= 35 cm.
Weight: 31 Kg
Consumption: 240 Watt (20A @ 12 VDC)
Power supply: 12 or 24 VDC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
Affordable, light and easy to install, SMART is the ideal solution for those who prefer a simple and essential system.
Watermaker SMART 100S12-24-220 100 lit/h :
Watermaker group dimensions: L= 120 D= 35 H= 27 cm.
Pump group dimension L= 37 D= 15 H= 23 cm.
Weight: 48 Kg
Consumption: 400 Watt (17A @ 24 VDC)
Power supply: 12 / 24 VDC or 230 VAC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
A wide output range is able to satisfy all needs. Modular systems are ideal for heavy use, even in severe conditions.
Watermaker MODULAR 100M12-24-220 100 lit/h :
Watermaker group dimensions: L= 75 D= 34 H= 41 cm.
Pump group dimension L= 37 D= 15 H= 23 cm.
Weight: 58 Kg
Consumption: 400 Watt (17A @ 24 VDC)
Power supply: 12 / 24 VDC or 230 VAC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
A wide output range is able to satisfy all needs. Modular systems are ideal for heavy use, even in severe conditions.
Watermaker MODULAR 210M220 210 lit/h :
Watermaker group dimensions: L= 120 D= 33 H= 40 cm.
Pump group dimension L= 50 D= 18 H= 25 cm.
Weight: 95 Kg
Consumption: 950 Watt (4,5A @ 230 VAC)
Power supply: 230 or 380 VAC
Pressure regulation: automatic
Pre-pump
Feed pump
Energy Recovery System Inside
|
|
A wide output range is able to satisfy all needs. Modular systems are ideal for heavy use, even in severe conditions.
Watermaker MODULAR 150M24-220 150 lit/h :
Watermaker group dimensions: L= 120 D= 27 H= 40 cm.
Pump group dimension L= 42 D= 15 H= 23 cm.
Weight: 69 Kg
Consumption: 600 Watt (26A @ 24 VDC)
Power supply: 24 VDC or 230 VAC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
This model is recommended in case of a generator on board.
Advantage of the SOLO models:
- low consumption (SOLO 60: 3A, SOLO 100: 5A)
- small dimension
- high outputs
- modular design allowing to adapt to small spaces
- reliability recognized for more than 30 years
|
|
The HP V series answers to the demands of spaces on board with regards to the mono block construction.
The vertical conception of the plant gives the possibility to insert the system in tight places. The base of the HP V is only 470 mm X 280 mm, and the height is 620 mm.
These measurements are referred to the body of the watermaker that in this case does not include the membranes that can be easily be installed vertically or horizontally everywhere. The watermakers of the V series are modular and can be supplied in the V KIT version (see the drawing in the following page ) without any extra cost.
|
|
HP SC ( Super Compact) is supplied on its frame. SC Series can be equipped of membranes 2521 (short) up to a production of 140 Lt/h and can produce up to 260 Lt/h with four membranes 2540.
SC Auto series is equipped of the automatic pressure regulation and automatic membranes flushing.
|
|
HP SC DOUBLE is supplied in a single block. It is a modular system composed by two independent machines, producing from 140 lt/h with two membranes 2540 up to 540 lt/h with 8 membranes.
The machine can be supplied in a MANUAL version, the AUTO version (with automatic membranes' flush) and eventually equipped with RP TRONIC system, the automatic pressure regulation.
|
|
The advantages of this product are:
- its small dimension
- its high outputs
- its modular design allowing to adapt to small spaces
- its reliability recognized for more than 30 years
|
|
Available from only 3.990 Euros: The Watermaker, reduced to the basic essentials for the reliable production of your fresh water. Purposely parts that are not needed for the basic and reliable water production were left out. The result is a Watermaker with the best price compared to performance, which works completely without any control electronics.
Only first-class components are used on this equipment ensuring a reliable and uncomplicated water supply on board. The heart of a desalination plant is the high-pressure unit. It must be able to produce up to 60 bar pressure and cope durable with the aggressive medium saltwater. Therefore the new AQUAGIV Watermaker comes with the Danfoss pump consisting of duplex and super duplex stainless steel, whose lifetime is at least 8000 hours without maintenance. Annoying oil changes are eliminated completely.
Ideal for refits and do-it-yourself installation.
|
|
The DUO is the first bi-powered water maker system world-wide.
It functions at the turn of a switch either on D.C. (12 or 24V) or on A.C. (120, 230 or 400V), as the DUO is an intelligent patented system.
Thanks to this system, the motors operate independently from each other, with neither electric clutch activation nor manual manipulation of the pulleys.
Like all Dessalator products the DUO is 100% reliable and safe. For over six years major shipyards have been including it as a standard fixture and since 2005 the DUO 100® has become indispensable for navigators.
The advantage of the DUO is its "2 in 1" aspect, as if there were two water makers available with the facility to function optimally and logically.
|
|
Ultra Compact watermaker with TERS
(Thermal Energy Recovery System).
It can be supplied in 12V - 24V - 220V 50Hz - 230V 60 Hz
|
|
Ultra Compact watermaker with TERS
(Thermal Energy Recovery System).
It can be supplied in 12V - 24V - 220V 50Hz - 230V 60 Hz
|
|
Compact, automatic, energy-saving, easy to install. All components of the Ready are assembled as a single unit.
The installation is easy, quick and inexpensive as only the connections necessary are the inlet and outlet hoses.
The first "all in one" new generation watermaker!
Watermaker READY 60R12-24 60 lit/h :
Watermaker group dimensions: L= 85 D= 35 H= 31 cm.
Weight: 38 Kg
Consumption: 240 Watt (20A @ 12 VDC)
Power supply: 12 or 24 VDC
Pressure regulation: automatic
Feed pump inside
Energy Recovery System Inside
|
|
Compact, automatic, energy-saving, easy to install. All components of the Ready are assembled as a single unit.
The installation is easy, quick and inexpensive as only the connections necessary are the inlet and outlet hoses.
The first "all in one" new generation watermaker!
Watermaker READY 30R12-24 35 lit/h :
Watermaker group dimensions: L= 85 D= 35 H= 31 cm.
Weight: 31 Kg
Consumption: 100 Watt (8A @ 12 VDC)
Power supply: 12 or 24 VDC
Pressure regulation: automatic
Feed pump inside
Energy Recovery System Inside
|
|
Affordable, light and easy to install, SMART is the ideal solution for those who prefer a simple and essential system.
Watermaker SMART 80S12-24-220 80 lit/h :
Watermaker group dimensions: L= 120 D= 28 H= 26 cm.
Pump group dimension L= 37 D= 15 H= 23 cm.
Weight: 35 Kg
Consumption: 380 Watt (16A @ 24 VDC)
Power supply: 12 / 24 VDC or 230 VAC
Pressure regulation: automatic
External feed pump
Energy Recovery System Inside
|
|
Pump motor unit together with the front panel on an ABS frame
We recommend this version when an engine room is available.
|
|
Tank capacities of boats tend more and more to reduce for a simple reason: to avoid excessive weights.
We conceived water makers with high outputs, which allows to quickly satisfy the requirements and to spare energy.
|
|
|
|
|
|
|
Our Little Wonder is the most durable 12-volt desalinator on the market, and perhaps the best value in the industry. When you consider such important factors as electrical consumption, water production, and dependability, then the Little Wonder enjoys the best reputation in the market place. We owe our success to skilled craftsmanship, the use of quality, non-corrosive materials and to our thirty years of reverse osmosis experience. Our exclusive lifetime guaranteed titanium high-pressure pump heads, fiberglass pressure vessel and high-grade stainless steel and titanium fittings, mean that the Little Wonder is built for a lifetime of use in the oceans around the world.
Like other Village Marine Tec. products, the Little Wonder was designed by boaters for boaters and is available in several styles: framed (LW 160-350), modular (LWM 160-200 and 300/350/400), and vertical framed (160/200). The framed unit is the most convenient to install: simply connect the hoses, run the power and you%u2019re in business. The modular system is ideal for sailboat applications by allowing the user the freedom to install components where space permits.
|
|
|
The Aqua Whisper watermakers produce from 450 to 1800 U.S. Gallons per day (1,703 to 6,814 liters per day). These watermakers combine small size, efficiency, and quiet operation due to its stainless steel triplex plunge pump.
|
|
|
The Ultra Whisper is a low power watermaker, engineered for boaters with limited electrical options. The very quiet Ultra Whisper features automatic operation and is easy to use with its simple Start and Stop controls. It serves as an efficient water supply, ideal for small power boats and sail boats.
|
|
|
Aqua Matic (patent pending), with comprehensive one touch automation...virtually eliminates the need for an operator. It requires no pressure adjustment and self-regulates to any feed water condition. The user-friendly touch screen displays pictorial images of all operating conditions, which can also be viewed with the optional remote touch screen controller from any location on the boat. All system readings can be selected to display either U.S. Standard or Metric measurements. Automatic shut down can be set for time duration or for a specified product water production amount. “For those who wish to be in control, the system may also be operated in manual mode”, says Rollins, whose company manufactures the first fully automated watermaker in the marine industry.
|
|
|
The Ultra Whisper is a low power watermaker, engineered for boaters with limited electrical options. The very quiet Ultra Whisper features automatic operation and is easy to use with its simple Start and Stop controls. It serves as an efficient water supply, ideal for small power boats and sail boats.
|
|
|
|
|
|
|
At last! A Spectra watermaker designed and engineered for the smaller vessel. The Ventura 150 (operates anywhere in the world) and the new Ventura 200T (tropical water applications only) are energy efficient, light weight, and self regulating. The Ventura is a very affordable compact watermaker with all the great features Spectra has become known for. The Ventura series is easy to install and use, quiet, very energy efficient, and it delivers up to 8 gallons of fresh product water (30 liters) per hour.
It’s ideal for installation in limited spaces on cruising and racing vessels. The exclusive Spectra-Clark Pump High-Pressure Intensifier maintains the proper pressures in the membrane throughout a wide range of temperatures and water conditions without any adjustments or loss of product water output. The machine’s composite construction is corrosion resistant for superior reliability. All this while producing all the water you need a day! With a Ventura aboard, there is no reason to compromise your creature comforts while cruising. You will have plenty of fresh water left over for boat and gear. Every Ventura comes complete and ready to install. Spectra’s High Pressure Intensifier is factory mounted with a 20 inch membrane in a Spectra high pressure vessel assembly. All high-pressure piping is pre-plumbed at the factory. Module brackets allow for installation in any orientation. Included with the Ventura is a complete installation kit, installation and operation manual, and warranty registration card. All you provide is the two thru-hull fittings and electrical connection.
|
|
|
|
