Inboard engine ODP (IP22)

propulsionelectricfor ships

Description Starting capacitors, cast iron frames, rigid base and oversized ball bearings to ensure extended motor life are all standard features. Remember to considered ambient temperatures and that ODP are suitable where dirt and moisture are at minimum. Applications Pumps Fans Conveyors Blowers Air compressors Refrigeration equipment Industrial equipment Milling machines Tools Farm equipment Aeration equipment Other moderate-to-high starting torque applications Standard Features Single-phase, II, IV and VI pole, 60Hz Squirrel cage rotor / Aluminum die cast NEMA dimensions Ball bearings Insulation Class 'F' High starting torque Continuous Duty (S1) 104ºF (40ºC) ambient temperature Altitude: 3300 ft (1000m) 1045 carbon steel shaft F1 mounting T-Box NPT threaded terminal box Stainless steel nameplate Paint: Enamel alkyd resin base Color: RAL 7022 - Dark Gray Service Factor: 1.25 (ODP only) 143/5T steel plate frames 182T up to 215T cast iron frames Service factor: 1.15 Automatic drain plugs V-ring slingers on both endshields Optional Features Special Voltages and frequency Stainless steel shaft C and D flanges available for all frames F2 mount
