Waterproof binoculars eDiscovery

autofocus10x42

Highlights

• First binoculars combining optical observation and integrated image capture
• 10x/42 mm optical system with Steiner optical design
• 13 MP photos and 4K video recorded through the optics

Overview
The STEINER eDiscovery 10x42 pairs 10x magnification with a fast 42 mm objective and Steiner optics to record high-detail images in challenging light (dawn, fog, backlight). Images and video are captured directly through the lenses and managed via the STEINER CONNECT 2.0 app for enlargement, analysis and sharing. The product is designed for field use and continuous availability when observation and documentation must be combined.

Key features

• Integrated camera: 13 MP photos and true 4K video captured through the optics
• Simple capture: two-button operation and app control via STEINER CONNECT 2.0
• Real-time Wi‑Fi transmission to up to five devices for guided use or team cooperation
• 10x/42 mm optical system with Steiner Auto Focus
• 64 GB internal storage and USB‑C connectivity
• Nitrogen-filled housing, NBR Longlife rubber armouring and ergonomic eyecups
• Waterproof to IP67 (1 m / 30 min); functional -10 °C to +60 °C
• Battery: 1x 18650 Li‑ion; operating time > 3 h (display on)

Features & product details

• Binoculars and camera in one: observation and documentation without additional equipment
• Direct capture through the optical path for images usable for analysis or reporting
• Live view and sharing via Wi‑Fi to multiple devices for collaborative tasks or guided demonstrations
• Quick documentation workflow: exportable photo/video files (mp4) and app-based management
• Compact field interface: two-button control with settings visible in the sight field

Technical data (table items)
Optical features
Magnification: 10x
Objective diameter: 42 mm
Exit pupil: 4.2 mm ±6%
Twilight factor: 20.49
Field of view at 1000 m: 108 m (6.17°)
AP distance (eye relief): 16 mm (+5.0 / –0.5 mm)
Display: Yes
Resolution: 13 MP
Video recording: 4K (mp4)

Function & Equipment
High-performance optics: Yes
Focusing system: Steiner Auto Focus
Nitrogen filling: Yes
Operating range: -10 °C to +60 °C
Waterproofness: IP67 (1 m / 30 min)
Eyecups: Ergonomic
Rubber armouring: NBR Longlife
Storage capacity: 64 GB (internal)
USB: USB‑C
Wi‑Fi: Yes

Specifications

• Model: eDiscovery 10x42
• Magnification: 10x
• Objective diameter: 42 mm
• Camera resolution: 13 MP (photos)
• Video: true 4K recording (mp4)
• Field of view: 108 m at 1000 m (6.17°)
• Exit pupil: 4.2 mm ±6%
• Eye relief: 16 mm (+5.0 / –0.5 mm)
• Focusing: Steiner Auto Focus
• Storage: 64 GB internal
• Connectivity: Wi‑Fi, USB‑C
• Power: 1x 18650 Li‑ion; operating time > 3 h (display on)
• Ingress protection: IP67 (1 m / 30 min)
• Operating temperature: -10 °C to +60 °C
• Housing: Nitrogen-filled, NBR Longlife rubber armouring
• Dimensions (W×H×D): 130 × 85 × 175 mm
• Weight: 955 g (1010 g with battery)
• Article number / SKU: 2350
