Boat blower SFBB1-250-05

marinebilgeengine room

Description
Marine bilge blower designed to ventilate engine compartments, galleys, bilges and heads. 05 series models SFBB1-250-05 (12V) and SFBB2-250-05 (24V) deliver high-volume airflow with a snail/eddy impeller and slide-in duct connection. White MPPO plastic housing and corrosion-resistant motor housings with front and rear shaft seals provide protection in marine environments. Ignition-protected design and CE conformity to EN50014-1 and EN61000-3-3.

Key features & benefits

• White MPPO corrosion-resistant housing
• High-efficiency snail/eddy impeller for 250/425 CFM performance
• Mounts on any flat surface
• Slide-in duct connection for easy installation
• Low current draw and ignition protection
• CE conformity: EN50014-1, EN61000-3-3

Standard configurations (table)
SFBB1-250-05 | 12V | 250/425 CFM | 12.0 A | 15.0 A
SFBB2-250-05 | 24V | 250/425 CFM | 6.0 A | 10.0 A

Additional notes
Intended for marine ventilation applications including engine compartments, galleys, bilges and heads. Front and rear shaft seals plus corrosion-resistant motor housings improve durability in saltwater environments.

Specifications

• Model: SFBB1-250-05 / SFBB2-250-05
• Series: 05 series Bilge blower
• Voltage: 12V (SFBB1), 24V (SFBB2)
• Air flow: 250 / 425 CFM
• Current: 12.0 A (SFBB1), 6.0 A (SFBB2)
• Fuse: 15.0 A (SFBB1), 10.0 A (SFBB2)
• Housing: White MPPO plastic, corrosion-resistant
• Mounting: Flat-surface mounting; slide-in duct connection
• Protection: Ignition protection; front and rear shaft seals
• Standards: CE (EN50014-1, EN61000-3-3)
