epoxy resin / laminating
1090 FRT

Add to MyNauticExpo favorites
Compare this product Don’t compare this product
epoxy resin / laminating epoxy resin / laminating - 1090 FRT
{{requestButtons}}

Characteristics

  • Type:

    epoxy

  • Applications:

    laminating

Description

Self-extinguishing epoxy system

Low viscosity & reactivity epoxy system
Low settling tendency
Improved wettability
Tg up to 80°C

DETAILS

1090 FRT -1093 HTD is a self-extinguishing epoxy resin system. It is possible to produce structural composite parts with all current reinforcements and core materials.

Thanks to its low viscosity and its reactivity, 1090 FRT can be laminated by traditional wet processes such as filament winding and hot forming. Hardener 1093 HTD is proportioned in the ratio of 19 parts hardener to 100 parts resin (by weight) and gives good glass transition temperature (80°C).

Once hardened, the parts can be released from the mould without post curing.

The optimal thermomechanical properties are obtained after an adapted cycle of curing. However, post-curing is not essential depending on the final use of the parts.

APPLICATION

It is recommended these products are used at a temperature close to 25°C in order to facilitate
mixing and the impregnation of reinforcements. Lower temperatures increase the viscosity of the mixture. On the contrary, a higher temperature decreases the viscosity of the mixture.
Thanks to its low viscosity and to its good absorptivity, system 1090 FRT - 1093 HTD is adapted to many applications including : structural laminating, infusion, wet lay up, pre-impregnated applications and filament winding

CURING & POST-CURING

While a post-cure is not mandatory, in order to obtain a material with maximum mechanical propertiesand a TG of 80°C, it is necessary to post-cure with a cycle of : 24h at ambient temperature (20-25°C) + 4h at 80°C.
