Structural epoxy laminating system
Adjustable working time from 14min to 8h45min
Excellent wetting out with all type of reinforcements
Same mixing ratio for the 3 hardeners
Manufacturing of small parts to very large composite structures
TG from up to 85°C after post cure
130°C TG with 1205HT & 1206HT hardeners
RESOLTECH 1200 / 1204 - 1206 - 1208 is a state of the art chemistry laminating epoxy system, formulated without reactive diluents (primary cause of allergies) thus improving the H&S working conditions. It allows to manufacture small parts as well as large composite structures & tools with all the existing fibers.
RESOLTECH 1200 / 1204 - 1206 - 1208 does not crystallize, these systems do not contain any CMR components and meet the latest requirements of European regulation & REACH.
With its adapted viscosity and its large range of reactivity, the system enables application by wet lay up, vacuum bagging and filament winding. A thixotropic version 1200T is available for applications such as vertical & overhanging laminates.
The hardeners 1204, 1206 and 1208 of this system have a mixing ratio of 35 parts for 100 parts of resin 1200 by weight. They are compatible and may be mixed together in order to adjust the reactivity needed.
After curing at room temperature the system 1200 / 1204 - 1206 - 1208 can be released directly from the mold. In order to accelerate the release after initial curing, a post cure at 40°C is possible. To obtain the optimum thermo mechanical properties a post cure at 60-80°C will be required.
Hardeners 1205HT and 1206HT will enable to obtain a TG of 130ºC after post cure making the 1200 a choice system for pre-preg tools.
