Patrol boat RIB830-M

rescue boatoutboardrigid hull

The Liya 8.3m (27FT) Heavy-Duty Patrol RIB is a professional-grade fast-response vessel.
※Combining a high-performance stepped deep-V fiberglass hull with premium ORCA Hypalon tubes, this CE B/C certified craft delivers exceptional speed, sea-keeping, and durability.
※Designed for law enforcement, emergency rescue, and coastal security tasks, it offers unparalleled configuration flexibility for up to 12 personnel, ensuring readiness for any mission profile.

Professional 8.3m Heavy-Duty Patrol RIB Boat
Fast-Response,12-Person,CE Certified

Tube Option:

1. France Orca Hypalon/Germany PVC inflatable tube

Hypalon tube:
Made of Orca Hypalon from France, this material has UV resistance, high and low temperature resistance, wear resistance, and can prevent fuel, chemical, water, and air leakage.

PVC tube:
Made of German PVC, its multi-stage design reduces the vulnerability of punctures.

Safety and design:
Both use British Leafield valves and segmented airtight seals to prevent leaks.
Hypalon wear-resistant strips have been added to protect the cylinder from wear and improve durability and safety.
Inflatable tube warranty: 3-5 years

2. Foam filled solid tube

Core structure:
The dense foam core provides permanent buoyancy, eliminating the risk of air leakage.

Durability advantage:
Designed to resist punctures, cracks, and ruptures.

3. D shaped foam tube: Made of foam with D shape, also available as customer's requirements.

Length overall............................................8.30m – 27’
Inside length.............................................8.10m - 26’
Width overall.............................................3.00m – 9.9’
Inside width...............................................1.75m – 5.8’
Tube diameter............................................0.55m-0.60m – 1.8’
V shape degree..........................................22°

Capacity
Capacity.......................................................6-12 people
Max loading.................................................1700kg
Net Weight (kg)............................................1600
Airtight compartment..................................8pcs
Category.......................................................C ,B
40ft HQ container.........................................2pcs

Outboard engine data
Single engine shaft.......................................XL 25’
Twin engine shaft.........................................XL 25’
Recommended power (Hp)..........................250
Max recommend power(HP)........................300(single) /2x150(twin)
Max power at additional cost(HP)...............400
Max speed (Knots)....................................... 45
