Outboard express cruiser ELITE 34 OB

twin-engineopencenter console

Overview
The Elite 34 marks the next evolution of Monterey’s award-winning Elite Series, expanding the lineup into the upper premium segment with greater scale, enhanced luxury appointments, and extended offshore capability. Designed to deliver commanding presence and confident performance, the 34 builds on the proven Elite foundation while introducing expanded entertaining space, elevated helm ergonomics, and refined detailing throughout.

Key Dimensions & Capacities

• LOA W/Swim Platform: 34'0" (10.36M) — Length Overall, including add-on swim platform, not including bow rail or anchor roller
• LOA W/Engines: 37'0" (11.28M) — Length Overall With Engines
• Beam: 10'6" (3.20M) — Width of hull at widest section including rubrail
• Deadrise: 21° — Angle of keel measured at transom
• Fuel Capacity: 320 GAL (1211 L)
• Water Capacity: 35 GAL (132.5 L)
• Waste Capacity: 28 GAL (106 L)
• Max Horsepower: 850 HP (634 KW)
• Max Persons: Yacht Certified

Specifications (from specification table)
LOA W/Swim Platform | US Unit: 34'0" | Metric Unit: 10.36M | Description: Length Overall, including add-on swim platform, not including bow rail or anchor roller
LOA W/Engines | US Unit: 37'0" | Metric Unit: 11.28M | Description: Length Overall With Engines
Beam | US Unit: 10'6" | Metric Unit: 3.20M | Description: Width of hull at widest section including rubrail
Deadrise | US Unit: 21° | Metric Unit: 21° | Description: Angle of keel measured at transom
Draft - Engine Up | US Unit: TBD | Metric Unit: TBD | Description: Depth of hull to lowest point, Engine trimmed up
Draft - Engine Down | US Unit: TBD | Metric Unit: TBD | Description: Depth of hull to bottom of engine, trimmed down
Fuel Capacity | US Unit: 320GAL | Metric Unit: 1211L | Description: Capacity of fuel tank in gallons/liters
Water Capacity | US Unit: 35GAL | Metric Unit: 132.5L | Description: Capacity of water tank in gallons/liters
Waste Capacity | US Unit: 28GAL | Metric Unit: 106L | Description: Capacity of waste tank in gallons/liters
Bridge Clearance W/Hardtop | US Unit: TBD | Metric Unit: TBD | Description: Height from water to highest point on tower, normal load
Max Persons | US Unit: Yacht Certified | Metric Unit: TBD | Description: Maximum Rated Persons Capacity
Dry Weight | US Unit: TBD | Metric Unit: TBD | Description: Mass of boat with engine(s) and batteries, no fuel, water, waste, or gear
Max Power | US Unit: 850HP | Metric Unit: 634KW | Description: Maximum horsepower for safe operation

Standards & Options (grouped by category)
Head

• Flooring, Sleek Teak — Standard
• Toilet, Electric w/Holding Tank, Indicator & Pump Out Deck Fitting — Standard
• Vanity w/Solid Surface Top, Sink and Pullout Sprayer — Standard

Cockpit

• Courtesy Lighting, Blue/White, LED RGB — Standard
• Cockpit Table w/Pedestal & Vertical Side Mount Bases, Fwd & Aft — Standard
• Drink Holders, Stainless Steel (11) — Standard
• Fiberglass Cockpit Liner with Non-Skid & Overboard Drainage — Standard
• Hardtop, Fiberglass w/Overhead RGB Lighting, Electrically Folding All-Around Light — Standard
• Outlets 12v/USB — Standard
• Stereo, Fusion Apollo RA770, (6) JL 7.7" Speakers, (2) 10" Subwoofers w/LED Lights, JL 600/6 Amp & 600/1 Amp — Standard
• Stereo Remotes, Bow & Stern — Standard
• Storage, In Floor — Standard
• Transom Shower (Cold Only) — Standard
• Wetbar w/Solid Surface Insert, Sink, Faucet, Trash Receptacle & Storage — Standard
• Yeti Cooler, 75Qt. Carry-On — Standard

Electrical System

• 3 Bank Battery Charger w/Deck Plug — Standard
• Battery Trays, Group 31 (4) — Standard
• Panel, Battery Switch w/Emergency Parallel, Remote Controlled, Dual — Standard

Engine Compartment

• Automatic Bilge Pumps — Standard
• Bilge Compartment Lighting — Standard
• Bilge Hatch, Fiberglass — Standard
• Gel Coated Bilge Compartment — Standard

Fuel Systems

• Double Clamped Fuel Lines — Standard
• Water Separating Fuel Filters — Standard

Helm

• Compass — Standard
• Cup Holders (4) — Standard
• GPS/Chart Plotter, Simrad 15" Ultra Wide B60 Transducer Integrated Switching and Stereo Controls — Standard
• Outlet 12v, USB (2) — Standard
• Steering Wheel, Leather Wrapped with Chromed Stainless Spokes — Standard
• Steering, Power Assisted — Standard
• Steering Tilt — Standard
• Wireless Chargers (6) — Standard

Hull & Deck

• Barrier Coat, Vinylester — Standard
• Bow and Stern Eyes, Stainless Steel, w/SS Backing Plate — Standard
• Bow Grab Handles — Standard
• Bow Plate, Stainless Steel — Standard
• Cleats, Stainless Steel, Pull-Up (6) — Standard
• Colored Hull — Standard
• Door Walk-Thru At Transom — Standard
• Drain Plug Brass Garboard — Standard
• Horn, Electric Flush Mount — Standard
• Lights, Navigation, LED (Hardtop Mounted) — Standard
• NMMA Certified — Standard
• Portlight, Opening in Head w/Screen — Standard
• Portlight, Opening in Cabin w/Screen — Standard
• Rub Rail, Heavy Duty w/Stainless Steel Insert — Standard
• Swim Platform, Molded in w/Telescoping Recessed Ladder and Hatch (2) — Standard
• Thru-Hulls, Stainless Steel Above Waterline — Standard
• Transhield Shipping Cover — Standard
• Underwater Lights, RGB LED (3) — Standard
• Universal Burnewin Mounts (2) — Standard

Seating

• Aft Facing Seat — Standard
• Aft Sunpad, with (2) Articulating Backrests, & Storage Compartments — Standard
• Bow Lounge w/USB Chargers and Magnetic Cup Holders — Standard
• Helm Seats, (3) w/Flip-Up Thigh Rise, Fold Down Armrests, and Fore/Aft Sliders — Standard

Under Water Gear

• Trim Tabs, Seakeeper Ride 600 — Standard

Cabin (Options)

• Refrigerator, 12V — Optional
• TV, 32" Smart TV — Optional

Canvas (Options)

• Aft Shade — Optional
• Aft Seat Cover — Optional
• Bow Cover — Optional
• Bow Shade - Gray — Optional
• Console Cover — Optional
• Console Side Weather Curtains — Optional
• Helm Seat Cover — Optional
• Mooring Cover — Optional

Additional Optional Hull & Deck Items

• Anchor Windlass w/SS Anchor, Rope and Chain — Optional
• Bow Thruster (Integrates with Joystick when selected) — Optional
• Colored Hull Bottom (Other Than Arctic Ice) — Optional
• Phender Pro Holders (6) — Optional
• Seadek Swim Platform Inlay — Optional
• Seakeeper 2 Gyro Stabilizer — Optional
• Generator 3.5KW Gas w/16K BTU AC Unit and 120V Outlets (2) — Optional

Technical & Electronics (Options)

• VHF, Simrad RS100 — Optional
• GPS/Chartplotter, Simrad Ultrawide 15", 2 additional — Optional
• FLIR Infrared Camera, M232 — Optional
• Radome, Simrad — Optional

Waste Systems (Options)

• Grey Water System — Optional
• Macerator With Overboard Discharge N/A w/Grey Water Option — Optional

Performance (selected configurations)

• Engine: Twin 250XXL DTS — Total HP: 500HP — Drive: Twin 250XXL OB — Prop: Enertia Eco-19-S — Max MPH: 54 — GPH @ Cruise: 14 @ 32E
• Engine: Twin 300XXL DTS — Total HP: 600HP — Drive: Twin 300XXL OB — Prop: Enertia Eco-19-S — Max MPH: 57 — GPH @ Cruise: 16 @ 34

caractéristiques / spécifications techniques

• Model: ELITE 34 OB
• Brand: Monterey Boats
• LOA w/Engines: 37'0" (11.28M)
• LOA w/Swim Platform: 34'0" (10.36M)
• Beam: 10'6" (3.20M)
• Deadrise: 21°
• Fuel Capacity: 320 GAL (1211 L)
• Water Capacity: 35 GAL (132.5 L)
• Waste Capacity: 28 GAL (106 L)
• Max Power: 850 HP
• Certification: Yacht Certified
