Adapter cable Y504-2-503

marinefor docks

The Reverse "Y" Adapter has two (2) maie plugs with spécial power isolation circuitry for added safety. When one (1) plug is connected to a receptacle, the circuitry isolâtes the second plug. The reverse "Y” provides 50A 125/250V power when only two (2) 30A 125V receptacles are available. Note: Reverse "Y” will NOT work with 50A 125V, 3-wire inlets. Power is provided in both circuits to the 4-wire inlet, but the dock side receptacles limit the current in each circuit to 30A. The two (2) 30A 125V receptacles must be supplied from a single power source providing 208V to 250V between them for proper opération.
