Indoor light strip LD70D

for boatcabinLED

The LD70, LD70-OP and the LD70D range of light fittings is a series of extremely shallow recessed LED downlights. They feature minimal bezel thicknesses and are available with an optional half or fully cowled bezel to give optimal glare control, making them ideal for ultra discreet lighting in display cabinets or under shelving. The LD70D is available with our standard narrow beam optic at a recess depth of 17mm, which allows for continuity with other LightGraphix products. Alternatively, where there is a requirement for an even shallower recess depth, the LD70 uses our new range of miniature optics and requires a recess depth of only 13mm. LD70-OP has an opal diffuser and no optic, creating a very wide, diffused spread of light. Available with no cowl (NC), half cowl (HC) & full cowl (FC) options. - Applications: Display and Shelf, Surface Mounted, Wall Wash, (50lm-200lm) Miniature range, CB Certified - Fixing: Spring Clips - LED Information: Cree XPG: 3 output options - 1.2W @ 350mA (LD70D-350), 1.7W @ 500mA (LD70D-500) and 2.4W @ 700mA (LD70D-700) - Materials: Anodised aluminium, Stainless steel spring clips - IP Rating: IP20 Technical Specifications / Features - Product type: Extremely shallow recessed LED downlight - Bezel: Minimal thickness, optional half or full cowl for glare control - Recess depth: 17mm (LD70D), 13mm (LD70), wide diffused (LD70-OP) - Optics: Standard narrow beam (LD70D), miniature optics (LD70), opal diffuser (LD70-OP) - Output: 1.2W @ 350mA, 1.7W @ 500mA, 2.4W @ 700mA - Material: Anodised aluminium, stainless steel spring clips - IP Rating: IP20 - Mounting: Spring clips - Certifications: CB Certified
